Fermax 4420 door controller
About this product
Please note: this is a non-returnable item (excluding faulty goods)
Fermax 4420 is a door controller.
The door controller manages the devices present in each access: reader, electric lock, exit push button, door sensor, etc. When installed in the secure zone (interior), it lets you increase the security of access to the installation, since the device that drives the electric lock is beyond the reach of manipulations. The door controller admits a reader for the entrance and another one for the exit and accepts Wiegand-26 bits or magstrip readers.
Reader wiring: 2 wires + screened twisted pair. Intercommunication wiring. 4 wires + screened twisted pair.
Key features
- Manages devices in each access including reader, electric lock, exit push button, door sensor
- Increases security by placing electric lock control inside secure zone
- Supports one entrance reader and one exit reader
- Compatible with Wiegand-26 bits or magstrip readers
- Reader wiring: 2 wires plus screened twisted pair
- Intercommunication wiring: 4 wires plus screened twisted pair
- Operates at 12VDC
- Fits 100 x 100mm boxes
If you are matching this to an existing installation, work from the 4420 part number rather than the description.
Specifications
Certifications
Specifications
| Brand Name | Fermax |
|---|---|
| Manufacturer Part Number | 4420 |
Certifications
| RoHS compliance | Exempt |
|---|---|
| WEEE Compliant | Exempt |
