Hanwha Vision XND-A6084RV dome IP camera
Free Delivery
£
623
07
(Incl. VAT)
About this product
Please note: this is a non-returnable item (excluding faulty goods)
The Hanwha Vision XND-A6084RV is a 2MP AI IR dome camera from the 2nd generation X series, with a 2.8~12mm varifocal lens (4.3x optical zoom), WiseIR to 50m and a Wisenet 9 SoC with dual NPU.
Key features
- 1/2.8" CMOS sensor, up to 60fps/50fps (60Hz/50Hz) in H.265/H.264
- 2.8~12mm lens, 4.3x optical zoom, horizontal view 120°~27°
- WiseIR IR LED illumination to 50m
- WDR: 150 dB
- AI object classification: person, face, vehicle and licence plate
- People counting, queue management, heatmap, vehicle counting and crowd counting
- PoE (IEEE802.3af, Class3) powered: max. 10.2W, typical 5.0W
- IP52 and IP55 (IEC 60529), IK10 (IEC 62262)
Frequently asked questions
What resolution and lens does the XND-A6084RV have?
It is a 2MP camera with a 2.8~12mm lens and 4.3x optical zoom.
How far does its IR reach?
WiseIR IR LED illumination reaches 50m.
How is it powered?
By PoE (IEEE802.3af, Class3), max. 10.2W and typically 5.0W.
What can its analytics detect?
It classifies person, face, vehicle and licence plate, and runs people counting, queue management, heatmap, vehicle counting and crowd counting.
What are its IP and IK ratings?
IP52 and IP55 (IEC 60529) and IK10 (IEC 62262).
£
623
07
Price
Technical Details
Specifications
Brand Name
Hanwha Vision
Manufacturer Part Number
XND-A6084RV
Product Series
X
Product Type
Dome Camera
Image Sensor
1/2.8" CMOS
Focal Length (mm)
2.8~12
Optical Zoom
4.3x
Horizontal Field of View
120°~27°
Wide Dynamic Range (dB)
150
IR Range
WiseIR 50m
Ethernet
Metal shielded RJ-45 (10/100BASE-T)
Edge Storage
Micro SD/SDHC/SDXC, max. 1TB x 1 slot
Operating Temperature
-10°C~+50°C
Input Voltage
PoE (IEEE802.3af, Class3)
Power Consumption
Max. 10.2W, typical 5.0W
Dimensions
ø160x118mm
Weight
1,032g
Colour
White
Ratings
IP52, IP55 (IEC 60529); IK10 (IEC 62262)
ONVIF
S, G, T, M
Specifications
| Brand Name | Hanwha Vision |
|---|---|
| Manufacturer Part Number | XND-A6084RV |
| Product Series | X |
| Product Type | Dome Camera |
| Image Sensor | 1/2.8" CMOS |
| Focal Length (mm) | 2.8~12 |
| Optical Zoom | 4.3x |
| Horizontal Field of View | 120°~27° |
| Wide Dynamic Range (dB) | 150 |
| IR Range | WiseIR 50m |
| Ethernet | Metal shielded RJ-45 (10/100BASE-T) |
| Edge Storage | Micro SD/SDHC/SDXC, max. 1TB x 1 slot |
| Operating Temperature | -10°C~+50°C |
| Input Voltage | PoE (IEEE802.3af, Class3) |
| Power Consumption | Max. 10.2W, typical 5.0W |
| Dimensions | ø160x118mm |
| Weight | 1,032g |
| Colour | White |
| Ratings | IP52, IP55 (IEC 60529); IK10 (IEC 62262) |
| ONVIF | S, G, T, M |
