Hanwha Vision QNO-7012R network camera, 4MP

Free Delivery
£ 238 74
(Incl. VAT)

About this product

Hanwha Vision QNO-7012R is a network camera from the Q range.

The QNO-7012R from Samsung is a 4 megapixel outdoor network IR bullet camera with 2.8mm lens with 2.8mm lens.

Key features

  • For remote surveillance needs, this network camera is best suited
  • Provides night vision of objects at a distance of up to 20 m
  • CMOS sensor is cheaper as compare to CCD and consumes less power while producing better HD videos
  • Up to 2560 x 1440 video resolution

If you are matching this to an existing installation, work from the QNO-7012R part number rather than the description.

£ 238 74
Ships from United Kingdom
28 days hassle free returns
Secure payment transactions
Price
£238.74 Incl. VAT
Add a WME Product Care Plan Includes warranty, replacement and repairs backed by WME
Why add a product care plan:
  • Full breakdown support
  • Full replacement if we can't repair your product within 10 days
  • All parts, labour and callouts included if necessary
  • Extended manufacturer warranty with faster turn arounds
  • Excludes accidental & cosmetic damages
By selecting one of these plans you agree to purchase WME Care Plan. Please read the Terms and Important information to ensure WME Care Plan is right for you. Compare prices of extended warranties for electrical goods at www.compareextendedwarranties.co.uk
WME Care
Technical Details
Specifications
Brand Name
Hanwha Vision
Manufacturer Part Number
QNO-7012R
Product Series
Q
Product Type
Network Camera
Technical information
Connectivity Technology
Wired
Effective resolution
4MP
Field of View
Diagonal, Horizontal, Vertical
Field of View (Horizontal)
107.5°
Field of View (Vertical)
59.70°
Lens Type
Fixed
Maximum Aperture
f/2
Maximum Frame Rate
30fps
Minimum Focal Length
2.80mm
Night Vision
Yes
Night Vision Type
Active Illumination, Near-Infrared (NIR)
Video Formats
H.264 / AVC, H.265 / HEVC, MJPEG
Video Resolution
1280 x 720
Video Signal Format
CVBS (Composite)
Wide Dynamic Range
Yes
Camera
Image Sensor Type
CMOS
Night Vision Distance
20.00m
Certifications
Ingress protection
IP66
Display & graphics
Maximum video resolution
2560 x 1440
Environmental conditions
Maximum Operating Temperature
55°C
Minimum Operating Temperature
-40°C
Operating Humidity
95%
Exposure
Longest Shutter Speed
1/5 Second
Minimum Illumination
0.0000lux
Shortest Shutter Speed
1/12000 Second
Interfaces/ports
Network (RJ-45)
Yes
Lens
Focal Length
2.8mm
Lens Included
Yes
Maximum Focal Length
2.80mm
Network & communication
Remote Management
Yes
Physical characteristics
Colour
Silver
Durability
Vandal Resistant, Weather Resistant
Form Factor
Bullet
Weight
700.00g
Power description
Input Voltage
12V DC
Product information
Diameter
70.00mm
Length
246.00mm
Mount Type
Conduit Box Mount, Gang Box Mount
Storage
Recording Formats
H.264, H.265 / HEVC
Storage Type
SD Card
Video
Analog Video Signal Format
CVBS (Composite Video Baseband Signal)
Maximum Resolution
1280 x 720
Miscellaneous
Features
Alarm Triggering, Auto Gain Control, Automatic White Balance, Back Light Compensation (BLC), Built-in IR LED, Built-in Microphone, Day/Night, Digital Noise Reduction, Motion Detection, Privacy Masking, SD Card Local Storage, Tamper Detection, Wide Dynamic Range
Impact protection
IK10
Indoor or outdoor use
Outdoor
Attributes
Input Voltage
12V DC
Weight
700.00g

Specifications

Brand Name Hanwha Vision
Manufacturer Part Number QNO-7012R
Product Series Q
Product Type Network Camera

Technical information

Connectivity Technology Wired
Effective resolution 4MP
Field of View Diagonal, Horizontal, Vertical
Field of View (Horizontal) 107.5°
Field of View (Vertical) 59.70°
Lens Type Fixed
Maximum Aperture f/2
Maximum Frame Rate 30fps
Minimum Focal Length 2.80mm
Night Vision Yes
Night Vision Type Active Illumination, Near-Infrared (NIR)
Video Formats H.264 / AVC, H.265 / HEVC, MJPEG
Video Resolution 1280 x 720
Video Signal Format CVBS (Composite)
Wide Dynamic Range Yes

Camera

Image Sensor Type CMOS
Night Vision Distance 20.00m

Certifications

Ingress protection IP66

Display & graphics

Maximum video resolution 2560 x 1440

Environmental conditions

Maximum Operating Temperature 55°C
Minimum Operating Temperature -40°C
Operating Humidity 95%

Exposure

Longest Shutter Speed 1/5 Second
Minimum Illumination 0.0000lux
Shortest Shutter Speed 1/12000 Second

Interfaces/ports

Network (RJ-45) Yes

Lens

Focal Length 2.8mm
Lens Included Yes
Maximum Focal Length 2.80mm

Network & communication

Remote Management Yes

Physical characteristics

Colour Silver
Durability Vandal Resistant, Weather Resistant
Form Factor Bullet
Weight 700.00g

Power description

Input Voltage 12V DC

Product information

Diameter 70.00mm
Length 246.00mm
Mount Type Conduit Box Mount, Gang Box Mount

Storage

Recording Formats H.264, H.265 / HEVC
Storage Type SD Card

Video

Analog Video Signal Format CVBS (Composite Video Baseband Signal)
Maximum Resolution 1280 x 720

Miscellaneous

Features Alarm Triggering, Auto Gain Control, Automatic White Balance, Back Light Compensation (BLC), Built-in IR LED, Built-in Microphone, Day/Night, Digital Noise Reduction, Motion Detection, Privacy Masking, SD Card Local Storage, Tamper Detection, Wide Dynamic Range
Impact protection IK10
Indoor or outdoor use Outdoor

Attributes

Input Voltage 12V DC
Weight 700.00g

Hanwha Vision QNO-7012R network camera

Hanwha Vision QNO-7012R network camera, 4MP

Who this is for

For the installer — this is the network camera supplied under Hanwha Vision part number QNO-7012R. Specify it by that part number.

The entries in the specification table are the ones held against this part number. Anything not listed there is not stated by us, and should be confirmed against the manufacturer's own documentation.

In plain English: this is a network camera made by Hanwha Vision. The part number QNO-7012R is the manufacturer's own code for this exact version of it.

Similar-looking items in the same family often differ only by a suffix on that code. If you are replacing something, match the code rather than the picture.

Buying this in the UK

We are a UK supplier and this network camera is sold and shipped from the UK. Prices are shown in pounds sterling.

This item is returnable under our standard returns terms. Faulty goods are handled separately and are never affected by a returns restriction.

We do not quote a warranty term for this part. Every supplier-stated term we have checked against the manufacturer's own document has turned out to be wrong, so we would rather say nothing than say something we cannot stand behind.

Ask us and we will check it for you. Your statutory rights are unaffected.

Stock on this line moves, and lead times move with it. Ask us for the current position before you commit to a date on site.

Questions we get asked

Is this the exact network camera I have been quoted? Check the manufacturer part number QNO-7012R against your quote. That code is the only reliable identity for this item.

Is there a datasheet? Yes — a document attached to this listing was checked and names this exact part number.

Can you check compatibility for us? Ask before you order and we will check it against the manufacturer's own documentation. We do not state compatibility that the record does not carry.

Why does the listing not answer every question? Because the specification held against QNO-7012R answers some questions and not others. We would rather leave a gap visible than fill it with something we cannot show you.

What if I order the wrong version? Tell us the installation you are matching and we will work back to the part number with you. That is a faster conversation than a return.

Do you hold this in stock? Availability on this line changes through the week, so the honest answer is to ask us on the day. We will give you the current position rather than a general one.
