HDview H512VDW IP PoE 5MP 2.8-12mm Dome Camera White
Free Delivery
£
150
44
(Incl. VAT)
2 Years Warranty
IP PoE 5MP 2.8-12mm Dome Camera White
About this product
About this product
The HDview H512VDW is an IP PoE 5MP 2.8-12mm Dome Camera White. Featuring a 2.8-12mm varifocal lens and a dome form factor, it is built for dependable professional installation.
Key Features
- No white light — infrared night vision only
- Supports PoE & 12V DC Inputs
- Built-in Microphone
- Supports Up to 128GB MicroSD Card
- ONVIF Compliant
- A 2.8-12mm varifocal lens
-
Download
- H512VDW Tech Sheet
£
150
44
FAST delivery by Order within
Price
Technical Details
Specifications
Dimensions (mm)
129 x 110 x 129
Storage Type
Micro SD, up to 256 GB
Materials
Metal
Mounting
Surface
Weight (Kg)
0.66
Warranty (Years)
2
Operating Voltage (V DC)
12
Power Consumption (W)
7.5
Other Power Sources
PoE (IEEE802.3af)
Sensor Size (")
1/2.7" Progressive CMOS
Lens size (mm)
2.8-12
Lens Type
Varifocal (Motorised)
Electronic Shutter Type
Auto / Manual
Speed (sec/°)
1 to 1/100000
Scanning System
Progressive Scan CMOS
Maximum IR Distance (m)
40
IR Wavelength (nm)
850
Video Bit Rate
128 Kbps - 6 Mbps
Microphone Supported
Built-in
Day/Night
IR-Cut filter with Auto Switch (ICR)
Hardware Reset Button
Built-in
ONVIF Compliant
Yes; Profile S, Profile G, Profile T
Compatible Products
The range of 24/7 Network Video Recorders 4, 8, 16, 32 and 64 Channels
Dimensions
Dimensions (mm)
129 x 110 x 129
Specifications
| Dimensions (mm) | 129 x 110 x 129 |
|---|---|
| Storage Type | Micro SD, up to 256 GB |
| Materials | Metal |
| Mounting | Surface |
| Weight (Kg) | 0.66 |
| Warranty (Years) | 2 |
| Operating Voltage (V DC) | 12 |
| Power Consumption (W) | 7.5 |
| Other Power Sources | PoE (IEEE802.3af) |
| Sensor Size (") | 1/2.7" Progressive CMOS |
| Lens size (mm) | 2.8-12 |
| Lens Type | Varifocal (Motorised) |
| Electronic Shutter Type | Auto / Manual |
| Speed (sec/°) | 1 to 1/100000 |
| Scanning System | Progressive Scan CMOS |
| Maximum IR Distance (m) | 40 |
| IR Wavelength (nm) | 850 |
| Video Bit Rate | 128 Kbps - 6 Mbps |
| Microphone Supported | Built-in |
| Day/Night | IR-Cut filter with Auto Switch (ICR) |
| Hardware Reset Button | Built-in |
| ONVIF Compliant | Yes; Profile S, Profile G, Profile T |
| Compatible Products | The range of 24/7 Network Video Recorders 4, 8, 16, 32 and 64 Channels |
Dimensions
| Dimensions (mm) | 129 x 110 x 129 |
|---|
