HDview H1C864R24TB IP 64CH NVR 24TB
About this product
The HDview H1C864R24TB is an IP 64CH NVR 24TB. Featuring 4 channel recording and 8MP resolution, it is built for dependable professional installation.
Key Features
- H.265 Video Compression for Efficient Storage
- Intelligent Features such as Line Cross Detection & Perimeter Intrusion Detection
- Continuous/Scheduled/Motion Detection/Intelligent Record Modes
- Remote Monitoring via APP
- 4 channel recording
In Detail
Part of ESP's professional surveillance range, this network video recorder is designed for dependable around-the-clock monitoring of commercial and domestic premises, capturing usable footage in demanding real-world conditions.
It pairs with ESP recorders, power supplies and accessories for a complete CCTV system, giving installers a consistent, well-supported platform to specify and maintain.
The HDview H1C864R24TB is a practical choice wherever a reliable network video recorder is required, supplied with full WME trade support and free UK delivery on orders over £129.
Technical Specifications
| Brand | HDview |
| Product code | H1C864R24TB |
| Dimensions (mm) | 448 x 442 x 93 |
| Maximum Capacity | 8 * 16TB |
| Weight (Kg) | >6 (excluding HDD) |
| Internal HDD | 24TB |
| Warranty (Years) | 2 |
| Resolution | 32MP, 16MP, 12MP, 8MP, 6MP, 5MP, 4MP |
| Power Consumption (W) | <50 (Without Hard Disk) |
| Operating Temperature (°C) | -10 to +50 |
| Inputs | 16 |
| Outputs | 10 |
| PoE Ports | 0 |
| Video Input Channels | 64 |
| Input Channels (RCA) | 1 |
| Channels (RCA) | 2 |
| Display Video Output | 2 x VGA, 2 x HDMI |
| USB Interface | 2 x USB2.0 Front |
| Compatible Products | The range of 24/7 HDview 5MP and 8MP and Rekor IP 2MP Cameras |
| S4POE: 4 Port PoE Switch 60W | Removeable Power Supply |
| S8POE: 8 Port PoE Switch 88W | Hotswappable HDD Bay accessible via the front |
| S16POE: 16 Port PoE Switch 225W | Corridor Mode Screen (3 & 4) |
| GTIN | 5061064590550 |
| Commodity Code | 8525890000 |
