HIKMICRO HM-TD2638-8/G1/T3Y Thermal & Optical Bi-spectrum Network Bullet Camera, 384 × 288 Thermal, 7.6mm Thermal Lens
Free Delivery
£
2,449
97
(Incl. VAT)
RRP: £2,939.96
About this product
The HIKMICRO HM-TD2638-8/G1/T3Y is a thermal & optical bi-spectrum network bullet camera that pairs a 384 × 288, 12 μm VOx thermal sensor with a 2688 × 1520 optical channel. It adds temperature exception alarms from -20°C to 150°C (± 8°C), fire and smoking detection, and human/vehicle detection with the GUANLAN Large-Scale AI Model.
Key features
- 384 x 288 Vanadium Oxide Uncooled Focal Plane Arrays thermal sensor with 12 μm pixel pitch
- NETD ≤ 20 mK (@25° C,F# = 1.0)
- 7.6 mm thermal lens with a 35° × 26.1° (H × V) field of view
- 1/2.7" Progressive Scan CMOS optical channel at 2688 × 1520 with a 4.3 mm lens
- IR distance up to 30 m
- Temperature measurement from -20 °C to 150 °C with ± 8 °C accuracy, 3 rule types and 21 rules in total
- Fire detection of up to 10 fire points and smoking detection of up to 10 smoking points
- IP67, IK10-rated housing and NEMA 4X anti-corrosion housing
Frequently asked questions
What is the thermal resolution of the HM-TD2638-8/G1/T3Y?
384 × 288 with a 12 μm pixel pitch and NETD ≤ 20 mK (@25° C,F# = 1.0).
Can it measure temperature?
Yes. It has 3 temperature measurement rule types (point, area, line) with 21 rules in total, over -20 °C to 150 °C with ± 8 °C accuracy.
How is it powered?
By 24 VAC ± 25% (max. 12.1W), 12 VDC ± 25% (max. 11.3W) or PoE (802.3af, class 3) (max. 11.8W).
How far does the IR reach?
IR distance is up to 30 m.
Is it suitable for outdoor use?
It is rated IP67 with an IK10-rated housing and NEMA 4X anti-corrosion housing, and works from -40°C to 70°C at 95% humidity or less.
What storage does it support?
A MicroSD/SDHC/SDXC card up to 512 G for local storage, plus NAS (NFS, SMB/CIFS) and Auto Network Replenishment (ANR).
£
2,449
97
RRP: £2,939.96
Save £489.99
Price
Technical Details
Specifications
Brand
HIKMICRO
Model
HM-TD2638-8/G1/T3Y
Manufacturer Part Number (MPN)
HM-TD2638-8/G1/T3Y
Thermal image sensor
Vanadium Oxide Uncooled Focal Plane Arrays
Thermal resolution
384 x 288
Pixel Pitch
12 μm
NETD
≤ 20 mK (@25° C,F# = 1.0)
Thermal focal length
7.6 mm
Thermal field of view
35° × 26.1° (H × V)
Thermal digital zoom
×2, ×4, ×8
Optical image sensor
1/2.7" Progressive Scan CMOS
Optical resolution
2688 × 1520
Optical min. illumination
0.0089Lux @(F1.6,AGC ON), 0 Lux with IR
Optical field of view
83.7° × 43° (H × V)
Optical focal length
4.3 mm
WDR
120 dB
Day & Night Mode
IR Cut Filter with Auto Switch
IR Distance
Up to 30 m
Main Stream
Optical channel 50 HZ: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720); 60 HZ: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720); Thermal channel 25 fps (1280×720P, 704×576, 352×288, 384×288)
Video Compression
Main Stream: H.265/H.264; Sub-Stream: H.265/H.264/MJPEG
VCA
4 VCA rule types (line crossing, intrusion, region entrance, and region exiting), up to 8 VCA rules in total
VCA Range For Humans
104 m
VCA Range For Vehicles
240 m
Temperature Measurement
3 temperature measurement rule types (point, area, line), 21 rules in total
Temperature Range
-20 °C to 150 °C (-4 °F to 302 °F)
Temperature Accuracy
± 8 °C (±14.4 °F)
Fire Detection
Up to 10 fire points detectable
Smoking Detection
Up to 10 smoking points detected
Color Palettes
17 types
Network Storage
MicroSD/SDHC/SDXC card (up to 512 G) local storage, NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR)
API
ISAPI, ISUP, HIKVISION SDK, and third-party management platform, ONVIF (Profile S, Profile G, Profile T, Profile M), OTAP
Simultaneous Live View
Up to 20 channels
Client
iVMS-4200, Hik-Connect
Alarm Input
2, alarm input (0-5 VDC)
Alarm Output
2-ch, relay outputs (alarm response actions configurable)
Audio Input
1, 3.5 mm Mic in/Line in interface
Communication Interface
1, RJ45 10 M/100 M Self-adaptive Ethernet interface; 1, RS-485 interface (half duplex)
Power Supply
24 VAC ± 25%, 12 VDC ± 25%, 24VDC two-core terminal block; PoE (802.3af, class 3)
Power Consumption
24 VAC ± 25%: 0.33 A to 0.55 A, max. 12.1W; 12 VDC ± 25%: 0.8 A to 1.33 A, max. 11.3W; PoE (802.3af, class 3): 36 V to 57 V, 0.33 A to 0.21 A, max. 11.8W
Working Temperature/Humidity
Temperature: -40°C to 70°C (-40°F to 158°F); Humidity: 95% or less
Protection Level
IP67 Standard; TVS 4000V lightning protection, surge protection, voltage transient protection; IK10-rated housing; NEMA 4X anti-corrosion housing
Dimensions
376.1 mm × 119.1 mm × 118.1 mm (14.81" × 4.68" × 4.65")
Weight
1.82 kg (4.01 lb)
Specifications
| Brand | HIKMICRO |
|---|---|
| Model | HM-TD2638-8/G1/T3Y |
| Manufacturer Part Number (MPN) | HM-TD2638-8/G1/T3Y |
| Thermal image sensor | Vanadium Oxide Uncooled Focal Plane Arrays |
| Thermal resolution | 384 x 288 |
| Pixel Pitch | 12 μm |
| NETD | ≤ 20 mK (@25° C,F# = 1.0) |
| Thermal focal length | 7.6 mm |
| Thermal field of view | 35° × 26.1° (H × V) |
| Thermal digital zoom | ×2, ×4, ×8 |
| Optical image sensor | 1/2.7" Progressive Scan CMOS |
| Optical resolution | 2688 × 1520 |
| Optical min. illumination | 0.0089Lux @(F1.6,AGC ON), 0 Lux with IR |
| Optical field of view | 83.7° × 43° (H × V) |
| Optical focal length | 4.3 mm |
| WDR | 120 dB |
| Day & Night Mode | IR Cut Filter with Auto Switch |
| IR Distance | Up to 30 m |
| Main Stream | Optical channel 50 HZ: 25 fps (2688 × 1520, 1920 × 1080, 1280 × 720); 60 HZ: 30 fps (2688 × 1520, 1920 × 1080, 1280 × 720); Thermal channel 25 fps (1280×720P, 704×576, 352×288, 384×288) |
| Video Compression | Main Stream: H.265/H.264; Sub-Stream: H.265/H.264/MJPEG |
| VCA | 4 VCA rule types (line crossing, intrusion, region entrance, and region exiting), up to 8 VCA rules in total |
| VCA Range For Humans | 104 m |
| VCA Range For Vehicles | 240 m |
| Temperature Measurement | 3 temperature measurement rule types (point, area, line), 21 rules in total |
| Temperature Range | -20 °C to 150 °C (-4 °F to 302 °F) |
| Temperature Accuracy | ± 8 °C (±14.4 °F) |
| Fire Detection | Up to 10 fire points detectable |
| Smoking Detection | Up to 10 smoking points detected |
| Color Palettes | 17 types |
| Network Storage | MicroSD/SDHC/SDXC card (up to 512 G) local storage, NAS (NFS, SMB/CIFS), Auto Network Replenishment (ANR) |
| API | ISAPI, ISUP, HIKVISION SDK, and third-party management platform, ONVIF (Profile S, Profile G, Profile T, Profile M), OTAP |
| Simultaneous Live View | Up to 20 channels |
| Client | iVMS-4200, Hik-Connect |
| Alarm Input | 2, alarm input (0-5 VDC) |
| Alarm Output | 2-ch, relay outputs (alarm response actions configurable) |
| Audio Input | 1, 3.5 mm Mic in/Line in interface |
| Communication Interface | 1, RJ45 10 M/100 M Self-adaptive Ethernet interface; 1, RS-485 interface (half duplex) |
| Power Supply | 24 VAC ± 25%, 12 VDC ± 25%, 24VDC two-core terminal block; PoE (802.3af, class 3) |
| Power Consumption | 24 VAC ± 25%: 0.33 A to 0.55 A, max. 12.1W; 12 VDC ± 25%: 0.8 A to 1.33 A, max. 11.3W; PoE (802.3af, class 3): 36 V to 57 V, 0.33 A to 0.21 A, max. 11.8W |
| Working Temperature/Humidity | Temperature: -40°C to 70°C (-40°F to 158°F); Humidity: 95% or less |
| Protection Level | IP67 Standard; TVS 4000V lightning protection, surge protection, voltage transient protection; IK10-rated housing; NEMA 4X anti-corrosion housing |
| Dimensions | 376.1 mm × 119.1 mm × 118.1 mm (14.81" × 4.68" × 4.65") |
| Weight | 1.82 kg (4.01 lb) |
