Hikvision DS-2CE10KF0T-LTS(3.6mm) 3K Two Way Audio Mini Bullet Camera, 3.6 mm Lens, Up to 30 m IR
About this product
The Hikvision DS-2CE10KF0T-LTS(3.6mm) is a 3K Two Way Audio Fixed Mini Bullet Camera with a 3.6 mm fixed lens and 3K, 2960 × 1664 resolution, for HD analogue CCTV with 1 HD analog output. It has a built-in mic and built-in speaker for real-time communication via built-in two-way audio, and up to 20 m white light and 30 m IR distance for night imaging.
Key features
- 3K, 2960 × 1664 resolution from a 3K CMOS sensor
- 24/7 color imaging with F1.0 aperture
- Smart-Hybrid Light with flexible lighting options: up to 20 m white light and 30 m IR distance
- Built-in mic and built-in speaker with audio over coaxial cable
- 3.6 mm fixed lens: horizontal FOV 90.0°, vertical FOV 50.2°, diagonal FOV 109°
- Water and dust resistant (IP67)
- Operating condition -40 °C to 60 °C, humidity 90% or less (non-condensing)
- Power: 12 VDC ± 25%, max.5.3 W
Frequently asked questions
How far can the DS-2CE10KF0T-LTS see at night?
It offers up to 20 m white light and 30 m IR distance. The supplement light type is Smart, IR and white light.
Does the camera have two-way audio?
Yes. It has a built-in mic and built-in speaker and provides real-time communication via built-in two-way audio, with audio over coaxial cable.
What is the field of view of the 3.6 mm version?
The 3.6 mm lens gives a horizontal FOV of 90.0°, a vertical FOV of 50.2° and a diagonal FOV of 109°.
How is the camera powered?
Power is 12 VDC ± 25%, max.5.3 W. Hikvision recommends using one power adapter to supply the power for one camera.
Is it suitable for outdoor mounting?
It is water and dust resistant (IP67) and operates from -40 °C to 60 °C at a humidity of 90% or less (non-condensing).
What video signal does it output?
It has 1 HD analog output, with TVI frame rates of 3K @10 fps/12.5 fps/20 fps/25 fps, 4 MP @25 fps/30 fps and 1080P @25 fps/30 fps. The signal system is PAL/NTSC.
Specifications
Specifications
| Brand | Hikvision |
|---|---|
| Model | DS-2CE10KF0T-LTS(3.6mm) |
| Manufacturer Part Number (MPN) | DS-2CE10KF0T-LTS(3.6mm) |
| Image Sensor | 3K CMOS |
| Max. Resolution | 2960 (H) × 1664 (V) |
| Min. Illumination | 0.001 Lux @ (F1.0, AGC ON), 0 Lux with white light |
| Shutter Time | PAL: 1/30 s to 1/50,000 s, NTSC: 1/15 s to 1/50,000 s |
| Day & Night | ICR |
| Angle Adjustment | Pan: 0° to 360°, Tilt: 0° to 90°, Rotate: 0° to 360° |
| Signal System | PAL/NTSC |
| Lens Type | 3.6 mm fixed lens |
| Focal Length & FOV (3.6 mm) | 3.6 mm, horizontal FOV: 90.0°, vertical FOV: 50.2°, diagonal FOV: 109° |
| Lens Mount | M12 |
| Microphone Pickup Distance | In a radius of up to 5 m |
| Speaker Rated Power | 2 W |
| Speaker Range | In a radius of up to 5 m |
| Supplement Light Type | Smart, IR, White Light |
| Supplement Light Range | IR: Up to 30 m, White Light: Up to 20 m |
| Frame Rate | TVI: 3K @10 fps/12.5 fps/20 fps/25 fps, 4 MP @25 fps/30 fps, 1080P @25 fps/30 fps |
| Day/Night Mode | Auto/Color |
| WDR | Digital WDR |
| Noise Reduction | 3D DNR |
| Audio Function | Echo Cancellation, AI Noise Reduction, Automatic Gain Control |
| Video Output | 1 HD analog output |
| Communication | HIKVISION-C |
| Power | 12 VDC ± 25%, max.5.3 W |
| Material | Metal |
| Dimension | 179 mm × 66 mm × 69.1 mm (7.1" × 2.6" × 2.7") |
| Weight | Approx. 430 g (0.9 lb.) |
| Operating Condition | -40 °C to 60 °C (-40 °F to 140 °F). Humidity 90% or less (non-condensing) |
| Protection | IP67 |
