Hikvision DS-TCP440-DB(E)(2.8mm) Dual-Sensor iBeacon Guidance Camera, 4MP, 2.8mm
About this product
The Hikvision DS-TCP440-DB(E)(2.8mm) is a 4 MP dual-sensor iBeacon guidance camera for car park guidance systems, detecting whether each parking space is occupied or free and recognising number plates. It monitors up to 6 parking spaces in two directions, with ANPR accuracy of ≥ 99.5% and parking space status detection accuracy of ≥ 99.99%.
Key features
- 4 MP resolution, max. 2560 × 1440
- ANPR with accuracy ≥ 99.5%
- Parking space status detection with accuracy ≥ 99.99%
- Detects up to 6 parking spaces (Max 6)
- 2.8 mm fixed lens, F2.0
- 140db WDR with defog and 3D noise reduction
- Two RJ45 interfaces for connecting cameras in series
- Power by Hikvision PoE, or 12 to 24 VDC wide-range voltage
Frequently asked questions
How many parking spaces can the DS-TCP440-DB(E)(2.8mm) monitor?
The number of detected parking spaces is Max 6, monitored in two directions by the dual-lens camera.
How accurate is its number plate recognition?
The built-in chip supports ANPR with accuracy ≥ 99.5%, and parking space status detection with accuracy ≥ 99.99%.
How is the camera powered?
It takes Hikvision PoE, or 12 to 24 VDC wide-range voltage. Two RJ45 interfaces support connecting cameras in series, and no power cord is needed.
What do the indicator colours mean?
Red indicates the parking space is occupied, green indicates it is free, and blue indicates it is reserved.
Can it work in a dark underground car park?
Yes. The 4.0 MP camera is applied in environments with low illumination such as underground garages, with 140db WDR and 3D noise reduction.
Can external indicator lights be added?
Yes. In separation mode, up to 3 external indicators showing red, green, yellow, blue, cyan and magenta can be connected.
Specifications
Specifications
| Brand | Hikvision |
|---|---|
| Model | DS-TCP440-DB(E)(2.8mm) |
| Manufacturer Part Number (MPN) | DS-TCP440-DB(E)(2.8mm) |
| Resolution | 4 MP |
| Sensor Type | 1/3" Progressive Scan CMOS |
| Max. Resolution | 2560 × 1440 |
| Lens Type | 2.8 mm |
| Aperture (2.8 mm) | F2.0 |
| Shutter | 1 to 1/100,000 s |
| WDR | 140db |
| Defog | supported |
| Day/Night Switch | Auto/Scheduled/Manual |
| Number Of Detected Parking Space | Max 6 |
| Image Format | JPEG |
| Video Bit Rate | 32 Kbps to 16 Mbps |
| ROI | 8 regions respectively for main stream and sub-stream, 6 levels for each region. |
| Network Storage | NAS (NFS, SMB/CIFS), auto network replenishment (ANR) together with high-end Hikvision memory card, memory card encryption and health detection are supported |
| API | ONVIF(PROFILE S,PROFILE G), ISAPI, SDK |
| Indicator Interface | 3*LED lamp interface |
| Power Supply | Hikvision PoE, or 12 to 24 VDC wide-range voltage |
| Protection Level | IP54 |
| Angle Adjustment | Pan: -30° to 30°, Tilt: 0° to 30° |
| Storage Temperature And Humidity | Temperature: -20 °C to 70 °C (- 4°F to 158 °F); Humidity: 95% (non-condensing) |
| Dimensions | 170 × 121 × 105 mm (6.7 × 4.8 × 4.2 inch) |
