Hikvision DS-TMC403-EL Ground-Mounted ANPR Camera, 4mm, Global Shutter
About this product
The Hikvision DS-TMC403-EL is a ground-mounted ANPR camera for vehicle entrance and exit control, recognising number plates and controlling a vehicle barrier gate through its relay output. It uses a 1/1.8" global shutter CMOS with built-in strobe lights, and holds up to 100,000 allowlist and blocklist entries, with offline barrier control under allowlist mode.
Key features
- 1/1.8" progressive scan global shutter CMOS, up to 2688 × 1520
- Built-in 9 strobe lights to suppress vehicle headlights
- LPR rate ≥98.5% and capture rate ≥99% (under recommended installation and lighting conditions)
- Relay output to control a vehicle barrier gate, plus offline control under allowlist mode
- Up to 100,000 allowlist and blocklist entries in total
- Loop, radar and video triggering
- Self-heating glass and temperature and humidity sensor to prevent fogging
- Electrophoretic coating and stainless steel base for corrosion resistance
Frequently asked questions
How accurate is the DS-TMC403-EL at reading number plates?
Under recommended installation and lighting conditions, the licence plate recognition rate is ≥98.5%, the capture rate is ≥99% and driving direction accuracy is ≥98%.
Can it open a barrier without a server?
It supports relay output to control a vehicle barrier gate, and offline control of the barrier gate under allowlist mode.
How many plates can it store?
Up to 100,000 allowlist and blocklist entries in total.
Does it read UK number plates?
The UK is among the ANPR supported countries and regions.
How is vehicle capture triggered?
It supports loop triggering, radar triggering and video triggering.
Will it work at night or in poor weather?
Built-in 9 strobe lights suppress vehicle headlights, IR supplement light is fitted, and global shutter technology maintains recognition in heavy rain or low illumination scenes.
Specifications
Specifications
| Brand | Hikvision |
|---|---|
| Model | DS-TMC403-EL |
| Manufacturer Part Number (MPN) | DS-TMC403-EL |
| Sensor Type | 1/1.8" Progressive Scan GMOS (Global shutter CMOS) |
| Max. Resolution | 2688 × 1520 |
| Shutter | 1/30 s to 1/100,000 s |
| Lens Type | 4mm |
| Aperture | F1.6 |
| Focal Length And FoV | 4 mm, horizontal FoV: 79°, vertical FoV: 43.3°, diagonal FoV: 92° |
| Supplement Light Type | IR Light |
| Scene Mode | Entrance and Exit Toll Gate, Underground Parking Entrance and Exit |
| Capture Resolution | 2688 × 1520 |
| License Plate Recognition | Forward, Backward, Bidirection |
| LPR Accuracy (under recommended installation and lighting conditions) | License plate recognition rate ≥98.5%; Capture rate ≥99%; Driving direction accuracy rate ≥98% |
| Main Stream | 50 Hz: 50 fps (2688 × 1520 (Default), 1920 × 1080, 1280 × 720) |
| Video Compression (main stream) | H.265/H.264/MJPEG |
| Barrier Gate Control Mode | By Camera/Platform/Mixed |
| Allowlist And Blocklist | Up to 100,000 allowlist and blocklist totally |
| Trigger Input | 3-ch triggered inputs |
| Trigger Output | 2-ch alarm output |
| Wiegand | 1-ch, Supported: CardID 26bit, SHA-1 26bit, Hik 34bit, NEWG 72bit |
| Alarm Input | 4-ch |
| RS-485 | 1-ch |
| RS-232 | 1-ch |
| Network Interface | 1 RJ45 10M/100M self-adaptive Ethernet port |
| Memory Card Slot | 1 TF card slot, up to 1TB |
| Relay Output | 4-ch |
| Power Output | 12VDC, max.1A |
