Hikvision Industrial 8-Port PoE Switch, 110W Budget, Gigabit + SFP, DS-3T1310P-SI/HS

Introduction to the Hikvision DS-3T1310P-SI/HS and its key features

The Hikvision DS-3T1310P-SI/HS is an industrial-grade, smart-managed Power over Ethernet (PoE) switch purpose-built for demanding surveillance and edge networking environments. Combining eight PoE ports, a total 110 W PoE budget, Gigabit uplinks (one RJ45 and one SFP), and a rugged industrial design, this switch targets installers and integrators who need reliable power and networking for IP cameras and other PoE devices in harsh sites. Key selling points include IEEE 802.3af/at support with up to 30 W per port, long-range PoE to 300 m, visual management integration with Hik-Partner Pro / Hik-Central, and hardened hardware that tolerates wide temperature swings and electrical surges.

Detailed specifications and benefits

Understanding what the DS-3T1310P-SI/HS brings to the table means looking at both its raw specifications and the real-world benefits they enable.

• 8 × 10/100 Mbps PoE RJ45 ports (ports 1–8)– Each port supports IEEE 802.3af/at standards and can deliver up to 30 W to power modern cameras, access points or other PoE devices.
• 110 W total PoE budget– The aggregate power pool allows flexible device mixes across ports while keeping the whole rooftop or site powered from one compact switch.
• Long-range PoE support– Ports support long-range mode, extending PoE delivery up to 300 m on copper runs. This is especially useful where fiber is not available and cameras are installed beyond standard 100 m Ethernet reach.
• Flexible uplinks– One Gigabit RJ45 uplink and one Gigabit SFP optical uplink give freedom to connect to a backbone network by copper or fiber for distance and isolation.

• Switching capacity and forwarding– A 9.2 Gbps switching capacity and 6.84 Mpps forwarding rate accommodate multiple cameras and data flows without becoming a bottleneck in small- to medium-sized deployments.
• Layer-2 feature set– VLAN (802.1Q), QoS, STP/RSTP, ERPS, static link aggregation and port mirroring enable administrators to segment traffic, prioritize video streams and build resilient ring topologies for uptime.
• Security and monitoring– SNMP, DHCP snooping, storm control and LLDP help protect the network and make integration with network management tools straightforward.

• Rugged enclosure– A metal shell with DIN-rail or desktop mounting fits industrial racks and control cabinets.
• Wide operating range– Rated for -30 °C to 65 °C operation and -40 °C to 85 °C storage, the switch withstands outdoor and factory conditions where consumer switches would fail.
• Surge protection– 6 kV surge protection helps guard equipment in locations exposed to lightning or electrical transients when combined with proper grounding practices.

• Power supply requirements– The switch requires a 48 V DC industrial power supply (spec sheet indicates 48 V DC, 2.5 A) and supports approved external DIN-rail supplies for centralized power installations.
• Manageability– Web management plus integration with Hik-Partner Pro and Hik-Central provides a visual topology and remote management for distributed sites, simplifying troubleshooting and firmware updates.

Use cases and scenarios where this switch excels

The DS-3T1310P-SI/HS is optimized for environments where equipment must survive tough conditions while powering and connecting IP devices reliably. Typical scenarios include:

• Distributed CCTV installations at manufacturing plants, warehouses, and utilities benefit from the PoE budget and extended temperature rating. The long-range PoE means fewer fiber runs and more flexibility when cameras are mounted far from central cabinets.

• Bus depots, rail yards, toll booths and traffic junctions need hardened networking gear. The 6 kV surge protection and DIN-rail mounting make this switch a practical choice in these applications.

• Small branch sites and remote substations that require a compact, managed PoE switch — with the ability to integrate into a centralized management platform — will find the device well suited to delivering both power and network management.

• When existing cabling prevents running new fiber, use the long-range PoE functionality to power cameras at distances up to 300 m, enabling cost-effective retrofit projects.

Comparisons with similar products in the market

There are several classes of switches that buyers might consider alongside the Hikvision DS-3T1310P-SI/HS. Below is a practical comparison focused on typical decision criteria: robustness, PoE budget, management features and price.

• Standard SMB switches from mainstream brands often provide Gigabit PoE ports and simple web management at lower cost, but they lack the wide operating temperature range, surge protection and long-range PoE features of the Hikvision unit. For outdoor or industrial CCTV, commercial-grade SMB switches are usually less suitable.

• Competitor industrial switches may offer similar environmental ratings, SFP uplinks and managed feature sets. When evaluating alternatives, check per-port power, total budget, and whether long-range PoE is natively supported.

• Enterprise-grade switches provide higher port densities, 1 G/10 G uplinks, advanced routing and enhanced QoS — but they come at a higher purchase and operational cost and may be overkill for many CCTV or edge PoE deployments. The Hikvision model aims to strike a balance between industrial toughness and cost-effectiveness for surveillance-centric use cases.

Installation, safety and compliance considerations

To get the best performance and longevity out of the DS-3T1310P-SI/HS, observe the following:

• Use a compliant 48 V DC industrial power supply or an approved DIN-rail power source as specified by Hikvision. Incorrect power wiring may damage the unit or connected devices.
• Employ proper grounding, cable management and surge protection especially for outdoor or lightning-prone locations. The built-in 6 kV surge protection helps but does not replace good site-level protection practices.
• Secure management access by changing default passwords, restricting remote management to trusted networks and keeping firmware updated to address security patches.

Conclusion — Why the DS-3T1310P-SI/HS is a strong choice

If you need a compact, rugged PoE switch tailored to surveillance and harsh-environment networking, the Hikvision DS-3T1310P-SI/HS offers a practical mix of features: a solid 110 W PoE budget, per-port 30 W capability, long-range PoE to 300 m, Gigabit uplinks including SFP, and an industrial-grade build that tolerates wide temperature ranges and electrical transients. Its Layer-2 management features, combined with Hikvision’s visual management ecosystem, simplify deployment and remote operations for distributed camera systems. For installers balancing cost and capability — particularly in CCTV, transportation, manufacturing or utility environments — this switch represents a cost-effective and fit-for-purpose option. As always, verify power and bandwidth needs for your specific camera mix, follow recommended installation and grounding practices, and integrate the switch into your management platform for the best long-term results.
