Hikvision DS-2CD6445G2-C1/HDMI Separated Network Camera, 4MP, HDMI Output
Free Delivery
About this product
The Hikvision DS-2CD6445G2-C1/HDMI is a 4 MP separated network camera main body for IP CCTV systems, with 1 standard HDMI video output, audio and alarm interfaces, and 4 TOPS of computing power for third party applications. Hikvision lists the DS-2CD6445G1-L30 separated network camera (lens) as its optional accessory.
Key features
- 4 MP resolution (2688 × 1520) on a 1/2.7" Progressive Scan CMOS
- 1 standard HDMI video output
- Hikvision Embedded Open Platform (HEOP) with 4 TOPS computing power for importing third party applications
- 1 audio input (line in) and 1 audio output (line out)
- 2 alarm inputs and 1 alarm output (max. 12 VDC, 30 mA)
- Line crossing, intrusion, region entrance and region exiting detection with human and vehicle target types
- Built-in memory card slot for microSD/microSDHC/microSDXC up to 256 GB
Frequently asked questions
Which lens unit goes with the DS-2CD6445G2-C1/HDMI?
Hikvision lists the DS-2CD6445G1-L30 separated network camera (lens) as the optional accessory for this main body.
Can it output video straight to a monitor?
Yes. It has 1 standard HDMI video output.
How is it powered?
By PoE (IEEE 802.3af, Class 3, max. 7.4 W) or by 12 VDC ± 20%, 0.53 A, max. 6.4 W.
Does it have audio and alarm connections?
Yes. It has 1 audio input (line in), 1 audio output (line out), 2 alarm inputs and 1 alarm output (max. 12 VDC, 30 mA).
What memory card does it take?
Its built-in memory card slot supports microSD/microSDHC/microSDXC cards up to 256 GB.
Can third party analytics apps be installed?
Yes. It supports Hikvision Embedded Open Platform (HEOP) and importing third party applications, with 4 TOPS computing power.
Technical Details
Specifications
Brand
Hikvision
Model
DS-2CD6445G2-C1/HDMI
Manufacturer Part Number (MPN)
DS-2CD6445G2-C1/HDMI
Product type
4 MP Separated Network Camera
Image Sensor
1/2.7" Progressive Scan CMOS
Max. Resolution
2688 × 1520
Main Stream
50 Hz: 25 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720)
Video Compression (main stream)
H.265/H.264
Region of Interest (ROI)
4 fixed regions for each stream
WDR
Digital WDR
Image Enhancement
BLC,HLC,3D DNR,Defog
Computing Power
4 TOPS
Deep Learning Structure
Caffe,PyTorch,TensorFlow
Video Output
1 Standard HDMI
Ethernet Interface
1 RJ45 10 M/100 M self-adaptive Ethernet port
On-Board Storage
Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB
Network Storage
NAS (NFS, SMB/CIFS)
Audio
1 input (line in), 1 output (line out)
Alarm
2 inputs, 1 output (max. 12 VDC, 30 mA)
RS-485
1 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
Power Output
12 VDC, max. 200 mA
Smart Event
Line crossing detection, intrusion detection, region entrance detection, region exiting detection (support alarm triggered by specified target types (human and vehicle)), audio exception detection
Simultaneous Live View
Up to 20 channels
Client
iVMS-4200, Hik-Connect
API
Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP
Power
12 VDC ± 20%, 0.53 A, max. 6.4 W
PoE
IEEE 802.3af, Class 3, 36 V to 57 V, 0.2 A to 0.13 A, max. 7.4 W
Material
Main body: Aluminum Alloy+PC
Dimension
105 mm × 78 mm × 26 mm (4.13" × 3.1" × 1.02")
Weight
Main body: approx. 175 g (0.38 lb.)
Length of Lens Cable
2 and 8 m (6.6 and 26.2 ft.)
Startup and Operating Conditions
-30 °C to 55 °C (-22 °F to 131 °F). Humidity 95% or less (non-condensing)
Specifications
| Brand | Hikvision |
|---|---|
| Model | DS-2CD6445G2-C1/HDMI |
| Manufacturer Part Number (MPN) | DS-2CD6445G2-C1/HDMI |
| Product type | 4 MP Separated Network Camera |
| Image Sensor | 1/2.7" Progressive Scan CMOS |
| Max. Resolution | 2688 × 1520 |
| Main Stream | 50 Hz: 25 fps (2688 × 1520, 2560 × 1440, 1920 × 1080, 1280 × 720) |
| Video Compression (main stream) | H.265/H.264 |
| Region of Interest (ROI) | 4 fixed regions for each stream |
| WDR | Digital WDR |
| Image Enhancement | BLC,HLC,3D DNR,Defog |
| Computing Power | 4 TOPS |
| Deep Learning Structure | Caffe,PyTorch,TensorFlow |
| Video Output | 1 Standard HDMI |
| Ethernet Interface | 1 RJ45 10 M/100 M self-adaptive Ethernet port |
| On-Board Storage | Built-in memory card slot, support microSD/microSDHC/microSDXC card, up to 256 GB |
| Network Storage | NAS (NFS, SMB/CIFS) |
| Audio | 1 input (line in), 1 output (line out) |
| Alarm | 2 inputs, 1 output (max. 12 VDC, 30 mA) |
| RS-485 | 1 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive) |
| Power Output | 12 VDC, max. 200 mA |
| Smart Event | Line crossing detection, intrusion detection, region entrance detection, region exiting detection (support alarm triggered by specified target types (human and vehicle)), audio exception detection |
| Simultaneous Live View | Up to 20 channels |
| Client | iVMS-4200, Hik-Connect |
| API | Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP |
| Power | 12 VDC ± 20%, 0.53 A, max. 6.4 W |
| PoE | IEEE 802.3af, Class 3, 36 V to 57 V, 0.2 A to 0.13 A, max. 7.4 W |
| Material | Main body: Aluminum Alloy+PC |
| Dimension | 105 mm × 78 mm × 26 mm (4.13" × 3.1" × 1.02") |
| Weight | Main body: approx. 175 g (0.38 lb.) |
| Length of Lens Cable | 2 and 8 m (6.6 and 26.2 ft.) |
| Startup and Operating Conditions | -30 °C to 55 °C (-22 °F to 131 °F). Humidity 95% or less (non-condensing) |
