Hikvision DS-2CE12KF0T-LTS(3.6mm) Two Way Audio Fixed Bullet Camera, 3K, 3.6mm
About this product
The Hikvision DS-2CE12KF0T-LTS(3.6mm) is a 3K two way audio fixed bullet camera with a 3.6 mm fixed lens, a built-in mic and built-in speaker for real-time communication. Smart-Hybrid Light gives up to 40 m white light and 40 m IR distance for night imaging, and video leaves through 1 HD analog output with audio over coaxial cable.
Key features
- 3K resolution, 2960 × 1664
- 24/7 color imaging with F1.0 aperture
- Smart-Hybrid Light: IR up to 40 m and white light up to 40 m
- Built-in two-way audio for real-time communication
- Audio over coaxial cable
- 3.6 mm fixed lens, horizontal FOV 90.0°
- 3D DNR for clean and sharp images
- Water and dust resistant (IP67)
Frequently asked questions
Does the DS-2CE12KF0T-LTS(3.6mm) have two-way audio?
Yes. It has a built-in mic and built-in speaker for real-time two-way communication; the mic picks up in a radius of up to 5 m and the 2 W speaker covers a radius of up to 5 m.
How far can it see at night?
Smart-Hybrid Light gives IR up to 40 m and white light up to 40 m, and the F1.0 aperture supports 24/7 color imaging.
How is the camera powered?
From 12 VDC ± 25%, max. 5.9 W. The maker recommends one power adapter to supply the power for one camera.
Can it be mounted outside?
It is water and dust resistant (IP67) and rated for -40 °C to 60 °C with humidity of 90% or less (non-condensing).
What resolution and frame rate does it output?
Up to 2960 × 1664 (3K). Over TVI it runs 3K @10 fps/12.5 fps/20 fps/25 fps, 4 MP @25 fps/30 fps and 1080P @25 fps/30 fps through 1 HD analog output.
What is the field of view of the 3.6 mm lens?
Horizontal FOV 90.0°, vertical FOV 50.2° and diagonal FOV 109°.
Specifications
Specifications
| Brand | Hikvision |
|---|---|
| Model | DS-2CE12KF0T-LTS(3.6mm) |
| Manufacturer Part Number (MPN) | DS-2CE12KF0T-LTS(3.6mm) |
| Image Sensor | 3K CMOS |
| Max. Resolution | 2960 (H) × 1664 (V) |
| Min. Illumination | 0.001 Lux @ (F1.0, AGC ON), 0 Lux with white light |
| Shutter Time | PAL: 1/30 s to 1/50,000 s, NTSC: 1/15 s to 1/50,000 s |
| Day & Night | ICR |
| Angle Adjustment | Pan: 0° to 360°, Tilt: 0° to 180°, Rotate: 0° to 360° |
| Signal System | PAL/NTSC |
| Lens Type | 3.6 mm fixed lens |
| Focal Length & FOV | 3.6 mm, horizontal FOV: 90.0°, vertical FOV: 50.2°, diagonal FOV: 109° |
| Lens Mount | M12 |
| Microphone Pickup Distance | In a radius of up to 5 m |
| Speaker Rated Power | 2 W |
| Speaker Range | In a radius of up to 5 m |
| Supplement Light Type | Smart, IR, White Light |
| Supplement Light Range | IR: Up to 40 m, White Light: Up to 40 m |
| Frame Rate | TVI: 3K @10 fps/12.5 fps/20 fps/25 fps, 4 MP @25 fps/30 fps, 1080P @25 fps/30 fps |
| Day/Night Mode | Auto/Color |
| WDR | Digital WDR |
| Image Enhancement | DWDR, BLC, HLC, Global |
| Noise Reduction | 3D DNR |
| Audio Function | Echo Cancellation, AI Noise Reduction, Automatic Gain Control |
| Video Output | 1 HD analog output |
| Power | 12 VDC ± 25%, max. 5.9 W |
| Material | Main body: Plastic; Front cover: Metal |
| Dimension | 211 mm × 83.5 mm × 80.7 mm (8.3" × 3.3" × 3.2") |
| Weight | Approx. 425 g (0.9 lb.) |
| Operating Condition | -40 °C to 60 °C (-40 °F to 140 °F). Humidity 90% or less (non-condensing) |
| Communication | HIKVISION-C |
| Protection | IP67 |
