HOCHIKI ATJ-EN(BLACK) analogue multi-heat sensor, Black
About this product
HOCHIKI ATJ-EN(BLACK) is an analogue multi-heat sensor.
ATJ-EN Is a Multi-Heat Sensor, which is fully compatible with Hochiki's ESP Analogue Addressable Protocol. ATJ-EN Incorporates a Variable Temperature heat element and a Rate of Rise heat element, both of which are controlled from the Control Panel, allowing either thermal element or both elements simultaneously to be active in making the fire decision. The sensor polling LEDs can also be controlled via the Control Panel (pulsing / non-pulsing).
Key features
- User selectable modes
- Incorporates Fixed Temperature and Rate of Rise Heat elements
- Twin LEDs allow 360° viewing; green when polling, turn red in fire
- Pulsing / non-pulsing controlled from panel
- Electronically addressed
- LPCB and VdS approved to classes A1, B and C
- SIL Level 2 approved variants available
If you are matching this to an existing installation, work from the ATJ-EN(BLACK) part number rather than the description.
-
Download
- ATJ-EN(BLACK) — Product Manual
Specifications
Miscellaneous
Physical characteristics
Power description
Technical information
Attributes
Specifications
| Brand Name | HOCHIKI |
|---|---|
| Manufacturer Part Number | ATJ-EN(BLACK) |
| Product Type | Heat Sensor |
Miscellaneous
| Compatibility | Hochikis ESP Analogue Addressable Protoco |
|---|
Physical characteristics
| Colour | Black |
|---|---|
| Height | 45.00mm |
Power description
| Input Voltage | 17-41V DC |
|---|
Technical information
| Maximum Relative Humidity | 95% |
|---|
Attributes
| Compatibility | Hochikis ESP Analogue Addressable Protoco |
|---|---|
| Input Voltage | 17-41V DC |
| Maximum Relative Humidity | 95% |
