Visonic 0-102562 motion mirror detector, Black
About this product
Please note: this is a non-returnable item (excluding faulty goods)
JCI PowerG 0-102562 is a motion mirror detector.
TOWER-20AM PG2, an innovative wireless outdoor PIR mirror detector, comprehensively addresses property owners' security needs for accurate intruder detection with minimum false alarms. TOWER-20AM PG2 features several innovative technologies to overcome demanding outdoor challenges such as rain, direct sunlight, animals, changes of light levels and more. JCI PowerG's revolutionary Octa-Quad™ technology, which uses eight PIR sensors, each acting as a Quad detector, enables the TOWER-20AM PG2 to accurately and reliably determine whether an alarm is justified.
A robust housing and patented anti-masking protection together provide exceptionally high resistance to vandalism and masking. The TOWER-20AM PG2 outdoor detector works together with JCI PowerG's PowerMaster advanced home security system to provide a complete solution for full protection of the house, inside and out.
Key features
- Superior outdoor detection with virtually no false alarms
- Innovative Octa-Quad technology can distinguish between a moving person, swaying trees and bushes, and a small animal, minimizing false alarms while ensuring effective detection of real threats
- PowerG, two-way, Frequency Hopping Spread Spectrum (FHSS-TDMA) technology - Provides robustness and reliability closer than ever to wired systems
- Prolonged battery life (3 years in typical use)
- Vandal-resistant design – Enabled by patented V-Slot® technology
- Unprecedented, complete anti-masking protection
- Market-leading black mirror optics – Provide exceptionally high immunity to false alarms from sunlight and car headlights
- Configured from the panel – No hardware switches and no need to re-open the detector once closed
If you are matching this to an existing installation, work from the 0-102562 part number rather than the description.
Specifications
General information
Technical information
Certifications
Environmental conditions
Physical characteristics
Power description
Product information
Miscellaneous
Attributes
Specifications
| Brand Name | JCI PowerG |
|---|---|
| Manufacturer Part Number | 0-102562 |
| Product Type | Motion Sensor |
General information
| Application/Usage | Outdoor |
|---|
Technical information
| Connectivity Technology | Wireless |
|---|---|
| Maximum Motion Sensing Distance | 12m |
| Maximum Outdoor Detection Range | 12m |
| Maximum Viewing Angle | 90° |
| Passive Infrared Sensor (PIR) | Yes |
| Sensor Type | Infrared Sensor |
| Wireless Technology | RF |
Certifications
| Security Grade | Grade 2 |
|---|
Environmental conditions
| Operating Temperature (T-T) | -35-60°C |
|---|
Physical characteristics
| Colour | Black |
|---|---|
| Height | 157.00mm |
| Width | 124.00mm |
Power description
| Input Voltage | 8-16V DC |
|---|---|
| Power Source | Battery |
Product information
| Length | 147.00mm |
|---|---|
| Mount Type | Wall Mount |
Miscellaneous
| Features | Anti-mask, Anti-Spray Perimeter grooves, False alarm free detection, Remote Maintainence, Robustness and reliability, Unique & anti vandal design |
|---|
Attributes
| Indoor or outdoor use | Outdoor |
|---|---|
| Input Voltage | 8-16V DC |
| Power Source | Battery |
