Kantech KT-SG-SC2 multi-technology reader
About this product
Please note: this is a non-returnable item (excluding faulty goods)
Kantech KT-SG-SC2 is a multi-technology reader.
The Kantech KT-SG-SC2 ioSmart Card and Multi-Technology Reader is a single gang smart card reader designed for secure access control. It supports multiple reading technologies including ioSmart Mobile Credential (BLE), ioSmart SSF, and 32-bit CSN/UID formats such as Mifare Plus EV1, Mifare Desfire, and ISO-14443B. The reader outputs 56-bit CSN/UID via OSDP protocol and accommodates communication through RS-485, Wiegand, and OSDP interfaces.
It features a compact form factor with dimensions of 115.8 x 71.5 x 24.7 mm, a 6-pole screwless connector, and operates on an input voltage ranging from 8.5V DC to 16V DC.
Key features
- ioSmart Gen 2 – Single Gang Smart Card reader
- Reading technology: ioSmart Mobile Credential (BLE), ioSmart SSF. 32-bit CSN/UID: Mifare Plus EV1 (ISO-14443A), Mifare Desfire (ISO-14443A), Mifare Desfire EV1 (ISO-14443A), Mifare Classic (ISO-14443A) and ISO-14443B
- OSDP: CSN/UID output is 56-bit
- Communicating RS-485
- Wiegand, OSDP
- Dimensions 115.8 x 71.5 x 24.7
- Connector 6 screwless poles
- Input voltage 8.5V DC to 16V DC
If you are matching this to an existing installation, work from the KT-SG-SC2 part number rather than the description.
Specifications
Specifications
| Brand Name | Kantech |
|---|---|
| Manufacturer Part Number | KT-SG-SC2 |
