Klaxon TCC-0007 sounder, Red
About this product
Please note: this is a non-returnable item (excluding faulty goods)
Klaxon TCC-0007 is a sounder.
The IS Sonos sounder beacon has been approved for use in potentially explosive atmospheres for Group I (Mining) and Group II (Above Ground) applications and incorporates a high Ingress Protected IP66 enclosure. The sounder beacon unit incorporates a two stage alarm option and has a total of 32 selectable tones, selectable via a dip switch on the PCB and produces up to 105dB at 1 Meter. A specially designed time saver base enables quick and easy installation of this unit with no extra cabling to be made to the head of the unit.
Connections are made to the base during the initial wiring phase which results in a faster more reliable installation. The sounder head simply twists and clicks into the pre-fixed base on commissioning avoiding any additional wiring and connections. This unit must be used in conjunction with an approved Zener Barrier or Galvanic Isolator.
The characteristics should not exceed Uo: 28v, Io: 93mA, Po: 660mW, Ci: 0, Li 0. The minimum value of Uo should not drop below 23.6v and the minimum value of Io should not drop below 50mA.
Key features
- Approved by ATEX, IECEx
- Group I MI Ex ia I Ma
- Group II IGD Ex ia IIC T6 Ga, Ex ia IIIC T85C Da
- Zones 0, 1, 2, 20, 21 and 22
- Conforms to: EN 60079-0:2012 + All:2013 (IEC 60079-0:2011) EN-60079-11:2012 + (IEC 60079-11:2011)
- Diode Polarised and End of line resistor compatible
- White base version available MOQ apply
- Dustproof and Weatherproof
- Amber lens
If you are matching this to an existing installation, work from the TCC-0007 part number rather than the description.
Specifications
Technical information
Certifications
Environmental conditions
Physical characteristics
Power description
Product information
Miscellaneous
Attributes
Specifications
| Brand Name | Klaxon |
|---|---|
| Manufacturer Part Number | TCC-0007 |
| Product Type | Sounder |
Technical information
| Alarm Type | Audible, Visual |
|---|---|
| Connectivity Technology | Wired |
| Light Colour | Orange |
| Operating Range | -40-55°C |
Certifications
| RoHS compliance | Compliant |
|---|---|
| WEEE compliance | Compliant |
Environmental conditions
| Sound Emission | 105dB |
|---|
Physical characteristics
| Colour | Red |
|---|---|
| Durability | Dustproof, Weatherproof |
| Height | 105.00mm |
| Lens Colour | Orange |
| Weight | 330.00g |
Power description
| Input Voltage | 24V DC |
|---|---|
| Power Source | DC Power |
Product information
| Bulb/Tube Type | LED Bulb |
|---|---|
| Diameter | 97.50mm |
Miscellaneous
| Compatibility | MTL 7728+ Shunt Diode Safety Barrier, MTL 7778AC Shunt Diode Safety Barrier 28V AC 600 OHM |
|---|
Attributes
| Compatibility | MTL 7728+ Shunt Diode Safety Barrier, MTL 7778AC Shunt Diode Safety Barrier 28V AC 600 OHM |
|---|---|
| Input Voltage | 24V DC |
| Power Source | DC Power |
| Weight | 330.00g |
