Knight Fire & Security AR065M flush contact
About this product
Please note: this is a non-returnable item (excluding faulty goods)
Knight Fire & Security AR065M is a flush contact.
AR065M is a push-fit, single reed flush contact. This contact is designed in such a way that magnetic interference from surrounding metals is reduced, allowing it to be used in steel-framed doors. However, this contact also functions perfectly well in timber frames and doors.
The barrel of this contact holds 4 sloped crush ribs, allowing it to easily slide into a 20mm diameter recess, locking at the contact plate, which is 24mm in diameter. The 5m length of 4-core provides contact with 2-cores for alarm and 2-cores for tamper.
Key features
- 4-core flush contact with 5m cable length
- Reduces magnetic interference from surrounding metals
- Barrel with 4 sloped crush ribs for easy sliding into 20mm recess
- 2-cores for alarm and 2-cores for tamper circuits
- Grade 2 security rating
If you are matching this to an existing installation, work from the AR065M part number rather than the description.
Specifications
Certifications
Specifications
| Brand Name | Knight Fire & Security |
|---|---|
| Manufacturer Part Number | AR065M |
Certifications
| Security Grade | Grade 2 |
|---|
