MAGDUO MAGDUO4 4 Zone Two Wire Fire Panel
About this product
The MAGDUO MAGDUO4 is a 4 Zone Two Wire Fire Panel.
Key Features
- Active end of line monitoring and head removal
- Ability to differentiate between smoke detector, heat detector or a manual call point alarms
- Alarm confirmation feature
- RS485 connection to up to 8 repeater panels
- Genuine ESP fire alarm panel supplied by WME
In Detail
Specified across commercial, industrial and multi-occupancy premises, ESP's fire alarm panel products are engineered for reliable life-safety performance and straightforward installation by qualified engineers. Robust construction and clear indication help ensure the system performs when it matters.
A dependable fire alarm system relies on quality components working together, and this unit integrates cleanly with ESP panels, detectors and sounders — a well-supported platform to design around and maintain.
The MAGDUO MAGDUO4 is a practical choice wherever a reliable fire alarm panel is required, supplied with full WME trade support and free UK delivery on orders over £129.
Technical Specifications
| Brand | MAGDUO |
| Product code | MAGDUO4 |
| Dimensions (mm) | 331 x 331 x 99 |
| Colour | Grey |
| Materials | Enclosure: V0 rated ABS |
| Maximum Detectors Per Zone | Up to 32 Devices (Dependant on Device Loading Units , 160 per Zone) |
| Sounders and Detectors Mixed on Zones | Yes |
| Maximum Cable Length Per Zone (m) | 500 |
| Weight (Kg) | 2.28 |
| Warranty (Years) | 3 |
| Supply Voltage (V AC) | 230 (Nominal 700mA) |
| Operating Voltage (V DC) | 21 -31 |
| Nominal Operating Voltage (V DC) | 24 |
| Nominal Operating Current (mA) | 700 |
| Maximum Cable Size (mm²) | 1.5 (2 Core Screened Fire Rated Cable) |
| Standby Supply | 2 x 12V 3.2 Ah SLA Battery (Sold Seperately) |
| PSU Output (4 Hour Continuous)(A) | 2.1 |
| Wiring Type | 2-Wire Conventional |
| Programmable Inputs | 2; 3.3 Volts @ 10mA (Un-Monitored) |
| Monitored Inputs | 1; 3.3 Volts @ 10mA |
| Maximum Devices Per Zone | Up to 32 Devices (Dependant on Device Loading Units , 160 per Zone) |
| Auxiliary Output | 24V DC @ 250mA |
| Monitored Outputs | 2 |
| Monitored Output Ratings | Rated at 28V DC @ 200mA each |
| Unmonitored Outputs | 2 |
| Unmonitored Output Ratings | Fire & fault; 30V DC @ 1A each |
| 2 Monitored Outputs | Rated at 28VDC @ 200mA each |
| 2 Un-Monitored Outputs | Fire & fault; 30VDC @ 1A each |
| Operating Temperature (°C) | +5 to +40 |
| GTIN | 5060224109809 |
| Commodity Code | 8531103000 |
