MAGDUOSW 2 Wire Sounder White
£
28
99
(Incl. VAT)
3 Years Warranty
2 Wire Sounder White
About this product
About this product
The MAGDUOSW, from ESP's Fire Protection range, is a white ceiling sounder for MAGDUO 2-wire conventional systems, compatible with the MAGDUO2, MAGDUO4 and MAGDUO8. It has volume level adjustment and a built-in end of line function, and its device wiring base is included.
Key features
- Ceiling mount sounder
- Sound output 90+ dB @ 1m
- Volume level adjustment
- Built-in end of line function; device wiring base included
- 2-wire conventional; compatible with MAGDUO2, MAGDUO4 and MAGDUO8
- Operating voltage 25.5 - 35 V DC (mains powered panel) or 21 - 26 V DC (battery powered panel)
- Current consumption 0.92 mA quiescent, 10 mA in alarm
- IP21C; maximum device loading units (DLU’s) 36
Frequently asked questions
Which panels is the MAGDUOSW compatible with?
The MAGDUO2, MAGDUO4 and MAGDUO8.
How loud is it?
90+ dB at 1m, with volume level adjustment.
Is a base included?
Yes. Its device wiring base is included.
Where is it mounted?
It is a ceiling mount sounder.
What voltage does it need?
25.5 - 35 V DC on a mains powered panel, or 21 - 26 V DC on a battery powered panel.
-
Download
- MAGDUOSW Tech Sheet
£
28
99
FAST delivery by Order within
Price
Technical Details
Specifications
Dimensions (mm)
ø105 x 72
Maximum Device Loading Units (DLU's)
36
Warranty (Years)
3
Operating Voltage (Mains Powered Panel)(V DC)
25.5 - 35
Maximum Cable Size (mm²)
1.5
Current Consumption (Quiescent)(mA)
0.92
Current Consumption in alarm state (mA)
10
Maximum Current Consumption
10mA
Wiring Type
2-Wire Conventional
Sound Output @ 1m (db)
90+
Ingress Protection
IP21C
Operating Temperature (°C)
-10 to +50
Compatible Products
Compatible with MAGDUO2, MAGDUO4 and MAGDUO8
Weight
0.3 kg
GTIN
5060654460068
Commodity Code
8531103000
Operating Voltage (Battery Powered Panel)(V DC)
21 - 26
Colour
White
Materials
ABS UL94:V2
Mounting
Ceiling
Standards
EN54-3
Features
Volume level adjustment; Built-in end of line function; Device wiring base included
Dimensions
Dimensions (mm)
ø105 x 72
Specifications
| Dimensions (mm) | ø105 x 72 |
|---|---|
| Maximum Device Loading Units (DLU's) | 36 |
| Warranty (Years) | 3 |
| Operating Voltage (Mains Powered Panel)(V DC) | 25.5 - 35 |
| Maximum Cable Size (mm²) | 1.5 |
| Current Consumption (Quiescent)(mA) | 0.92 |
| Current Consumption in alarm state (mA) | 10 |
| Maximum Current Consumption | 10mA |
| Wiring Type | 2-Wire Conventional |
| Sound Output @ 1m (db) | 90+ |
| Ingress Protection | IP21C |
| Operating Temperature (°C) | -10 to +50 |
| Compatible Products | Compatible with MAGDUO2, MAGDUO4 and MAGDUO8 |
| Weight | 0.3 kg |
| GTIN | 5060654460068 |
| Commodity Code | 8531103000 |
| Operating Voltage (Battery Powered Panel)(V DC) | 21 - 26 |
| Colour | White |
| Materials | ABS UL94:V2 |
| Mounting | Ceiling |
| Standards | EN54-3 |
| Features | Volume level adjustment; Built-in end of line function; Device wiring base included |
Dimensions
| Dimensions (mm) | ø105 x 72 |
|---|
