Nitek VH4-56 balun
About this product
Please note: this is a non-returnable item (excluding faulty goods)
Nitek VH4-56 is a balun.
The VH456 is a four port active video mini-hub with gain and loss control, built-in surge suppression, ground loop isolation and video detection. Systems operate with other Nitek UTP video equipment including video transceiver hubs, standard video balun transceivers, active transmitters or any twisted pair equipped camera. These active video mini-hubs are multi-channel video receiver devices that provide a low cost means of receiving quality live video over category UTP cabling.
The systems can also adapt to existing communication and computer network spare pairs or new cable installations. The VH456 can be used on video runs up to 3,000' (900m) when used with passive transmitters or distances of up to 6,000' (1,800m) with the Nitek TT560 active transmitter. These hubs provide superior immunity from noise and interference, even when run in common raceways with AC.
Key features
- Quality video over ordinary twisted pair
- Built-in surge suppression
- Built-in ground loop isolation
- Convenient access to DIP switches for accurate gain and loss control
- Immunity to noise and interference
- LED’s to indicate video detection
- Compact design Video can be run in the same cable with telephone, computer signals and power
- Made in the USA
Specifications
Physical characteristics
Specifications
| Brand Name | Nitek |
|---|---|
| Manufacturer Part Number | VH4-56 |
Physical characteristics
| Depth | 116.84mm |
|---|---|
| Height | 45.72mm |
| Width | 139.70mm |
