Nitek ET1500U-W1 extender transmission device

Please note: this is a non-returnable item (excluding faulty goods)

Nitek ET1500U-W1 is an extender transmission device.

The Nitek Etherstretch ET1500UW is an Outdoor IP Network Extender-PoE Inserter component. The ET1500UW includes a NEMA 4X / IP66 rated enclosure to house the Transmitter. The Weatherproof Transmitter Enclosure makes it possible to take the network outdoors to devices located in hostile environments.

The ET1500UW is part of a system that operates in conjunction with either a ER8500U or ER16500U 8 or 16 Port IP Extender/Gigabit PoE Switch Receiver Unit (these receivers are sold separately), to form a multi-channel IP extender system that transmits IP cameras or other network devices well beyond standard network limitations. The Nitek Ethernet Extender Systems can turn standard network cables into a high speed network communication and PoE paths. When operating over category cables, UTP network extender system can operate for distances of up to 600m (1968').

The ET1500UW Ethernet Extender Transmitter requires very little installation time and absolutely no set up or configuration. The ET1500UW Ethernet Extender Transmitter is transparent to the network and has no IP or MAC addressing. Simply connect your network devices to the network ports of the Transmitter along with existing cabling and the system begins communicating.

LED indicators show the status of network communication and PoE power. When connected to a PoE switch, power from the switch is used as the power source for the connected ET1500UW Transmitter. In applications where network switches are not PoE capable, an optional power Inserter (IP1054 sold separately) can be used to insert power to the ET1500UW Transmitter.

The power is sent from the Receiver over the UTP to the Transmitter. The Transmitter uses PoE as its power source and powers the connected PoE network device as well.

Key features

• Supports 10/100 and PoE over category rated cables up to distances of 600m (1968')
• Transmitter is housed in a NEMA 4X rated enclosure for outdoor applications
• Fully transparent to the network
• Supports any network device, including Mega-pixel technology IP devices
• Easy to install, no set up required
• LED indicators for network signals, link status and power
• Optional power supply can insert PoE power for non-PoE switches
• Surge protected inputs
• Ground loop isolation

If you are matching this to an existing installation, work from the ET1500U-W1 part number rather than the description.
