Nitek EL1500C-W1 media converter

Please note: this is a non-returnable item (excluding faulty goods)

Nitek EL1500C-W1 is a media converter.

The Etherstretch EL1500CW Outdoor IP Devices over Coax Network Extender-PoE Inserter is another of the IP Video Transmission Solutions from Nitek. The System includes a Receiver, Transmitter, and a NEM 4X / IP66 rated enclosure to house the transmitter unit. The system transmits IP devices over Coax and can quickly turn any ordinary RG59U coaxial cable into a high speed network communication and PoE path.

When operating over RG59U coaxial cable, the Coax Network Extender Solution can operate for distances of up to 500 meters (1640'). The EL1500CW Coax Ethernet Extender Solution consists of a weatherproof enclosure which houses the Transmitter. The Etherstretch EL1500CW requires very little installation time and absolutely no set up or configuration.

The EL1500CW Ethernet over Coax Network Extenders Transmitter and Receiver are transparent to the network and have no IP or MAC addressing. Simply connect your network devices to the network ports of the Transmitter and Receiver along with existing cabling and the system begins communicating. LED indicators show the status of network communication and PoE power.

When connected to a PoE switch, power from the switch is used as the power source for the connected EL1500CW Receiver. In applications where network switches are not PoE capable, an optional power Inserter (IP1054 sold separately) can be used to insert power to the EL1500CW Receiver. The power is sent from the Receiver over the Coax to the Transmitter.

The Transmitter uses PoE as its power source and powers the connected PoE network device as well. The EL1500CW Coax Network Extender Solution extends network communications to overcome cable distance limitations offering connections to devices in locations traditional networking does not allow.

Key features

• NEMA4X Rated Enclosure to House Transmitter
• Transmits up to distances of 500m (1640')
• Supports PoE and network communications
• Supports any network device, including IP cameras
• Fully transparent to the network
• Built-in surge protection
• Easy to install, no set up required
• No MAC or IP addressing required
• LED indicators for network signals, link status and power
• Optional power supply can insert POE power for non-POE switches

If you are matching this to an existing installation, work from the EL1500C-W1 part number rather than the description.
