Nitek EL1500C-WS1 media converter

Please note: this is a non-returnable item (excluding faulty goods)

Nitek EL1500C-WS1 is a media converter.

The Etherstretch EL1500CWS Outdoor Ethernet over Coax network extender-PoE Inserter with Surge Suppression is another of the IP Video Transmission Solutions from NITEK. The System includes a receiver, transmitter, surge suppression unit and a NEMA4X rated enclosure to house the transmitter and surge units. The system transmits Ethernet IP cameras over coax and can quickly turn any ordinary RG59U coaxial cable into a high speed network communication & PoE path.

When operating over RG59U coaxial cable, the Ethernet over coax network extender system can operate for distances of up to 500 meters (1,640'). The EL1500CWS coax ethernet extender system consists of a weatherproof enclosure which houses the transmitter and also a receiver, which requires very little installation time & absolutely no set up or configuration. The EL1500CW ethernet over coax network extenders transmitter and receiver are transparent to the network and have no IP or MAC addressing.

Simply connect your network devices to the network ports of the transmitter and receiver along with existing cabling and the system begins communicating. LED indicators show the status of network communication and PoE power. When connected to a PoE switch, power from the switch is used as the power source for the connected EL1500CWS receiver.

In applications where network switches are not PoE capable, an optional power Inserter (IP1054 sold separately) can be used to insert power to the EL1500CWS receiver. The power is sent from the receiver over the coax to the transmitter. The transmitter uses PoE as its power source and powers the connected PoE network device as well.

The EL1500CWS coax network extender system extends network communications to overcome cable distance limitations offering connections to devices in locations traditional networking does not allow.

Key features

• Supports 10/100 and PoE over RG59 cables up to distances of 500m (1600')
• Transmitter housed in a NEMA 4X rated enclosure for outdoor applications
• Fully transparent to the network
• Supports any network device, including mega-pixel technology IP cameras
• Easy to install, no set up required
• No MAC or IP addressing required
• LED indicators for network signals, link status and power
• Ground loop isolation
• Designed to IP 65 of IEC 529 and NEMA 1, 2, 4, 4x, 12, and 13 Specifications
• Cover attaching screws are outside the sealing area, preventing ingress of moisture and dust

If you are matching this to an existing installation, work from the EL1500C-WS1 part number rather than the description.
