Nitek IPCOAX-1 network surge protector
About this product
Please note: this is a non-returnable item (excluding faulty goods)
Nitek IPCOAX-1 is a network surge protector.
The IPCOAX1 is a single channel IP Camera and PoE plus Surge Protector with an independent protection circuit for 12 or 24V power, for applications where heater units or higher power PTZ units may be required. The IPCOAX1 is an in-line, IP over Coax network surge protector for 10/100 or Gigabit network devices with a separate input for 12 or 24 VAc or DC power. The IPCOAX1 IP Ethernet over Coax Surge Protector is designed to provide surge protection for one network port.
The unit has female BNC connectors at the input and output to protect the network cable and push-in terminals for the 12-24V supply. The IPCOAX1 is ideally suited for small or restricted spaces when network protection is needed. The unit provides a heavy, single point ground connection and is easy to install in minutes.
The IPCOAX1 is recommended for use with the Etherstretch family of products to provide IP network and PoE plus protection.
Key features
- Ethernet over Coax protection in 10/100 or Gigabit Networks
- Heavy single point ground
- Easy to install
- Separate power protection for 12 or 24VDC/VAC
If you are matching this to an existing installation, work from the IPCOAX-1 part number rather than the description.
Specifications
Physical characteristics
Specifications
| Brand Name | Nitek |
|---|---|
| Manufacturer Part Number | IPCOAX-1 |
Physical characteristics
| Depth | 45.72mm |
|---|---|
| Height | 22.86mm |
| Width | 63.50mm |
