Nitek VB37-M video balun transceiver, Black

£ 41 81
(Incl. VAT)

About this product

Please note: this is a non-returnable item (excluding faulty goods)

Nitek VB37-M is a video balun transceiver.

The VB37M is a high noise immunity passive UTP Video balun for twisted pair transmission of CCTV video. The VB37M is a "heavy duty" design with two screw terminals for UTP connection and a female BNC for coax connection. This passive UTP video balun operates with other passive video baluns, transceivers or active receivers.

The VB37 series is available in the M model (male BNC) and the F model (female BNC). The VB37M UTP transceiver provides a low cost means of sending live video over unshielded twisted pair, point-to-point wiring for distances of up to 750 feet (225 meters) with other CCTV balun transceivers, up to 1,500' (450m) with the TR515 single channel receiver and model 51 series hubs, and up to 3,000' (900m) with the TR560 single channel receiver and model 56 Series hubs. The VB37M is compatible with all the "up-the-coax" control systems.

A basic system uses (2) video balun transceivers, one at each end of a twisted pair of wires. These units are intended for use over existing in-house telephone wiring, Category 5 wiring or other twisted pair cable runs to provide a convenient, cost-effective alternative to coax. The VB37 series units are designed to provide superior immunity from noise and interference even when running next to line power.

The VB37F alaso provides a convenient mounting tab for installation. The VB37F is a UTP transceiver that provides another Security Transmission Solution from Nitek.

Key features

  • Works with any HD/TVI/CVI/AHD or NTSC and PAL
  • Quality video over ordinary twisted pair cable
  • Immunity to noise and interference
  • Passive devices - do not require power
  • Video and P/T/Z over a single pair (with "up-the- coax" systems)
  • Mounts directly to camera or video source
  • Weather resistant design

If you are matching this to an existing installation, work from the VB37-M part number rather than the description.

£ 41 81
Ships from United Kingdom
28 days hassle free returns
Secure payment transactions
Price
£41.81 Incl. VAT
Add a WME Product Care Plan Includes warranty, replacement and repairs backed by WME
Why add a product care plan:
  • Full breakdown support
  • Full replacement if we can't repair your product within 10 days
  • All parts, labour and callouts included if necessary
  • Extended manufacturer warranty with faster turn arounds
  • Excludes accidental & cosmetic damages
By selecting one of these plans you agree to purchase WME Care Plan. Please read the Terms and Important information to ensure WME Care Plan is right for you. Compare prices of extended warranties for electrical goods at www.compareextendedwarranties.co.uk
WME Care
Technical Details
Specifications
Brand Name
Nitek
Manufacturer Part Number
VB37-M
Physical characteristics
Colour
Black
Depth
24.13mm
Height
33.02mm

Specifications

Brand Name Nitek
Manufacturer Part Number VB37-M

Physical characteristics

Colour Black
Depth 24.13mm
Height 33.02mm

Nitek VB37-M video balun transceiver

Nitek VB37-M video balun transceiver, Black

Who this is for

For the installer — this is the video balun transceiver supplied under Nitek part number VB37-M. Specify it by that part number.

The entries in the specification table are the ones held against this part number. Anything not listed there is not stated by us, and should be confirmed against the manufacturer's own documentation.

In plain English: this is a video balun transceiver made by Nitek. The part number VB37-M is the manufacturer's own code for this exact version of it.

Similar-looking items in the same family often differ only by a suffix on that code. If you are replacing something, match the code rather than the picture.

Buying this in the UK

We are a UK supplier and this video balun transceiver is sold and shipped from the UK. Prices are shown in pounds sterling.

This item is non-returnable, excluding faulty goods. That restriction comes from the manufacturer's own terms for this line.

We do not quote a warranty term for this part. Every supplier-stated term we have checked against the manufacturer's own document has turned out to be wrong, so we would rather say nothing than say something we cannot stand behind.

Ask us and we will check it for you. Your statutory rights are unaffected.

Stock on this line moves, and lead times move with it. Ask us for the current position before you commit to a date on site.

Questions we get asked

Is this the exact video balun transceiver I have been quoted? Check the manufacturer part number VB37-M against your quote. That code is the only reliable identity for this item.

Is there a datasheet? Not on this listing.

Can you check compatibility for us? Ask before you order and we will check it against the manufacturer's own documentation. We do not state compatibility that the record does not carry.

Why does the listing not answer every question? Because the specification held against VB37-M answers some questions and not others. We would rather leave a gap visible than fill it with something we cannot show you.

What if I order the wrong version? Tell us the installation you are matching and we will work back to the part number with you. That is a faster conversation than a return.

Do you hold this in stock? Availability on this line changes through the week, so the honest answer is to ask us on the day. We will give you the current position rather than a general one.

Nitek VB37-M video balun transceiver
Nitek

Nitek VB37-M video balun transceiver, Black

£41.81

Please note: this is a non-returnable item (excluding faulty goods)

Nitek VB37-M is a video balun transceiver.

The VB37M is a high noise immunity passive UTP Video balun for twisted pair transmission of CCTV video. The VB37M is a "heavy duty" design with two screw terminals for UTP connection and a female BNC for coax connection. This passive UTP video balun operates with other passive video baluns, transceivers or active receivers.

The VB37 series is available in the M model (male BNC) and the F model (female BNC). The VB37M UTP transceiver provides a low cost means of sending live video over unshielded twisted pair, point-to-point wiring for distances of up to 750 feet (225 meters) with other CCTV balun transceivers, up to 1,500' (450m) with the TR515 single channel receiver and model 51 series hubs, and up to 3,000' (900m) with the TR560 single channel receiver and model 56 Series hubs. The VB37M is compatible with all the "up-the-coax" control systems.

A basic system uses (2) video balun transceivers, one at each end of a twisted pair of wires. These units are intended for use over existing in-house telephone wiring, Category 5 wiring or other twisted pair cable runs to provide a convenient, cost-effective alternative to coax. The VB37 series units are designed to provide superior immunity from noise and interference even when running next to line power.

The VB37F alaso provides a convenient mounting tab for installation. The VB37F is a UTP transceiver that provides another Security Transmission Solution from Nitek.

Key features

If you are matching this to an existing installation, work from the VB37-M part number rather than the description.
