Nitek VB43-ATF video balun

£ 51 27
(Incl. VAT)

About this product

Please note: this is a non-returnable item (excluding faulty goods)

Nitek VB43-ATF is a video balun.

Power video balun to combine CCTV video, camera power and data for camera control for operation over twisted pair up to 750' (225m) in conventional UTP applications, 100 meters in TIA/EIA 568 applications. The VB43ATF is a unique transmission device which provides an economical means of sending video, camera power and 2 wire control signals over a standard Category 5 cable. Video is sent over one pair, 2 wire control signals over a second pair and camera power is sent over the two remaining pairs.

A mini-coax pigtail with male BNC is used on the VB43ATF. Two pair of screwless terminals are provided to connect 2 wire control signals and power (wires are provided for these connections). Connections to the Category 5 cable are made via an RJ45 connector.

The VB43ATF power video balun provides the same high immunity to noise and interference as all of the Nitek baluns. This simplified wiring scheme provides a convenient method of powering the camera, allowing for quicker and easier installations. The RJ45 modular jack uses standard 568B wiring so spare network cables can be used.

The VB43ATF also offers indication lights for the presence of power and data.

Key features

  • Intelligent light link indication
  • Superior video over ordinary twisted pair cable
  • Quick connect screwless terminals
  • Immunity to noise and interference
  • Rugged ABC flame retardant casing
  • Built-in surge suppression
  • Passive devices do not require power
  • Convenient connection to Category cable for video power and 2-wire control signals Easier to install than coax

If you are matching this to an existing installation, work from the VB43-ATF part number rather than the description.

£ 51 27
Ships from United Kingdom
28 days hassle free returns
Secure payment transactions
Price
£51.27 Incl. VAT
Add a WME Product Care Plan Includes warranty, replacement and repairs backed by WME
Why add a product care plan:
  • Full breakdown support
  • Full replacement if we can't repair your product within 10 days
  • All parts, labour and callouts included if necessary
  • Extended manufacturer warranty with faster turn arounds
  • Excludes accidental & cosmetic damages
By selecting one of these plans you agree to purchase WME Care Plan. Please read the Terms and Important information to ensure WME Care Plan is right for you. Compare prices of extended warranties for electrical goods at www.compareextendedwarranties.co.uk
WME Care
Technical Details
Specifications
Brand Name
Nitek
Manufacturer Part Number
VB43-ATF
Physical characteristics
Depth
31.75mm
Height
22.10mm
Width
47.50mm

Specifications

Brand Name Nitek
Manufacturer Part Number VB43-ATF

Physical characteristics

Depth 31.75mm
Height 22.10mm
Width 47.50mm

Nitek VB43-ATF video balun for accessories

Nitek VB43-ATF video balun

Who this is for

For the installer — this is the video balun supplied under Nitek part number VB43-ATF. Specify it by that part number.

The entries in the specification table are the ones held against this part number. Anything not listed there is not stated by us, and should be confirmed against the manufacturer's own documentation.

In plain English: this is a video balun made by Nitek. The part number VB43-ATF is the manufacturer's own code for this exact version of it.

Similar-looking items in the same family often differ only by a suffix on that code. If you are replacing something, match the code rather than the picture.

Buying this in the UK

We are a UK supplier and this video balun is sold and shipped from the UK. Prices are shown in pounds sterling.

This item is non-returnable, excluding faulty goods. That restriction comes from the manufacturer's own terms for this line.

We do not quote a warranty term for this part. Every supplier-stated term we have checked against the manufacturer's own document has turned out to be wrong, so we would rather say nothing than say something we cannot stand behind.

Ask us and we will check it for you. Your statutory rights are unaffected.

Stock on this line moves, and lead times move with it. Ask us for the current position before you commit to a date on site.

Questions we get asked

Is this the exact video balun I have been quoted? Check the manufacturer part number VB43-ATF against your quote. That code is the only reliable identity for this item.

Is there a datasheet? Not on this listing.

Can you check compatibility for us? Ask before you order and we will check it against the manufacturer's own documentation. We do not state compatibility that the record does not carry.

Why does the listing not answer every question? Because the specification held against VB43-ATF answers some questions and not others. We would rather leave a gap visible than fill it with something we cannot show you.

What if I order the wrong version? Tell us the installation you are matching and we will work back to the part number with you. That is a faster conversation than a return.

Do you hold this in stock? Availability on this line changes through the week, so the honest answer is to ask us on the day. We will give you the current position rather than a general one.
