Notifier D2E duct smoke detector
About this product
Please note: this is a non-returnable item (excluding faulty goods)
Notifier D2E is a duct smoke detector.
D2E 2-Wire Photoelectric duct smoke detector features a pivoting housing that fits various applications both square and rectangular footprints mount to round or rectangular duct work. This new duct smoke detector senses airflow speeds ranging from 0.5-20 m per second. The enhancements built into this model improve false alarm immunity (with plug-in sensor head) and humidity (0 to 95 percent non-condensing) ranges, while simplifying installation and maintenance.
These advance features can detect smoke even in the harshest duct applications. The new design provides more wiring space with an added 20mm conduit knockout. Numbers and labels for terminal designations are consistent with previous models.
The new sampling tube can be clicked into position with one smooth motion from either the front or the back of the detector. A cover tamper feature is incorporated to indicate a trouble condition for removed or improperly installed sensor cover. An improved cover design, with an integrated the low-flow feature, isolates the sensor head from the low-flow technology for simple maintenance.
The D2E series is designed for greater flexibility and reliable smoke detection to simplify installation and maintenance. The new device is backward compatible to existing models, including remote test accessories.
Key features
- Greater flexibility, round or rectangular ductwork
- Both square and rectangular footprints
- Improve false alarm immunity
- Plug-in sensor head
- Backward compatible to existing models
- Anti tamper contact
- Detector base B401 (included)
- Clear cover for convenient visual inspection
- Terminal block for optical repeater
If you are matching this to an existing installation, work from the D2E part number rather than the description.
Specifications
Environmental conditions
Physical characteristics
Power description
Attributes
Specifications
| Brand Name | Notifier |
|---|---|
| Manufacturer Part Number | D2E |
| Product Type | Smoke Detector |
Environmental conditions
| Operating Relative Humidity (H-H) | 0-95% |
|---|---|
| Operating Temperature (T-T) | -20-60°C |
| Storage Temperature (T-T) | -20-60°C |
Physical characteristics
| Weight | 0.82kg |
|---|
Power description
| Input Voltage | 8.5-35V DC |
|---|
Attributes
| Input Voltage | 8.5-35V DC |
|---|---|
| Weight | 0.82kg |
