Paxton Access 860-010G hands-free keyfob, Green
About this product
Please note: this is a non-returnable item (excluding faulty goods)
Paxton Access 860-010G is a hands-free keyfob.
About – Hands-free access control means the token that identifies a user is read from within a pocket or handbag. This is useful for loading doors and where disabled or elderly people require access. The hands-free tokens, in conjunction with the hands-free interface, achieve this using unique wireless technology.
Installation – Hands-free tokens will work as a standard token with all proximity readers. P series readers and KP series keypads equipped with a hands-free interface will achieve longer ranges. When installing a system, the first token pack is added by presenting the Enrolment card from that pack.
Subsequent packs are added by presenting the original Enrolment card followed by the Enrolment card from the new pack. Operation – The tokens are supplied packaged with a corresponding shadow card. Once installation of the system is complete all user cards are valid and ready to be issued.
To issue a user token, remove it from the packet and write the name of the user on its corresponding shadow card. The user may now use their token to gain access. This process is repeated for all users.
If a card needs to be invalidated, the corresponding shadow card is removed from the wallet and presented to any relevant readers on the site. This invalidates the card. They give a range of between 0.85 and 2.5m on any reader equipped with a hands-free interface, and 5m with the long range reader.
They work in passive mode with all other Paxton proximity readers.
Key features
- From 0.85m to 2.5m read range with a hands-free keyfob
- Works as standard passive token with non hands-free readers
- Up to 5m read range with the long range reader
- Use with P and KP readers (with the hands-free interface) and the long range reader
If you are matching this to an existing installation, work from the 860-010G part number rather than the description.
-
Download
- 860-010G — Product Manual
Specifications
General information
Miscellaneous
Physical characteristics
Attributes
Specifications
| Brand Name | Paxton Access |
|---|---|
| Manufacturer Part Number | 860-010G |
| Product Type | ID Card Kit |
General information
| Packaged Quantity | 10 |
|---|
Miscellaneous
| Compatibility | Paxton Devices Switch2 P and KP readers (with the hands free interface) and the Long range reader |
|---|---|
| Features | Read range of0 mP.85 mPm to2 mP.5 mPm with a hands-free interface, Up to5 mPm read range with the long range reader, Use with P and KP readers (with the hands-free interface) and the long range reader, Works as standard passive keyfob with non hands-free readers |
| Package Contents | Hands free keyfob housing top cover, logo Hands free keyfob Switch2 battery housing, details Net2 keyfob PCB, green , ISO Enrolment PROXIMITY card ISO door open time card ISO fail open release card ISO silent operation card Proxdisc coil module, ht2 for hands free fob, black , Label - product serial number label 27x10mm Label - Void if seal is broken, 80x30mm Token wallet - Demo packs (167mm x 167mm) Small polythene resealable bag 76x89mm Printed ISO card, green , Misc - black permanent marker pen Battery - Lithium 3V CR2032 coin cell 20mm Plastic - Hands free keyfob battery cover Fasteners - 1.8 x 4mm, small pozi pan PV self tapping black , Packaging - box OD 210x180x120mm, card packs (dac) Packaging - Box OD 125x63x22mm cardpack (crd) Packaging - tray insert for hands free keyfob, mk2 Label - Hands free keyfob, inner ratings |
Physical characteristics
| Colour | Green |
|---|
Attributes
| Compatibility | Paxton Devices Switch2; P and KP readers (with the hands free interface) and the Long range reader |
|---|---|
| Package Contents | Hands free keyfob housing top cover, logo Hands free keyfob Switch2 battery housing, details Net2 keyfob PCB, green , ISO Enrolment PROXIMITY card ISO door open time card ISO fail open release card ISO silent operation card Proxdisc coil module, ht2 for hands free fob, black , Label - product serial number label 27x10mm Label - Void if seal is broken, 80x30mm Token wallet - Demo packs (167mm x 167mm) Small polythene resealable bag 76x89mm Printed ISO card, green , Misc - black permanent marker pen Battery - Lithium 3V CR2032 coin cell 20mm Plastic - Hands free keyfob battery cover Fasteners - 1.8 x 4mm, small pozi pan PV self tapping black , Packaging - box OD 210x180x120mm, card packs (dac) Packaging - Box OD 125x63x22mm cardpack (crd) Packaging - tray insert for hands free keyfob, mk2 Label - Hands free keyfob, inner ratings |
