Safety Technology International STI-3150 security cover, Surface Mount
About this product
Safety Technology International STI-3150 is a security cover from the STI-1100 range.
Easy-to-use push button with cover allows urgent reaction during an emergency. This ADA Compliant, multipurpose push button switch with EMERGENCY EXIT label protects a wide range of applications indoors. The button incorporates a unique, patented design that helps dramatically to stop accidental activation.
Housing is molded of tough polycarbonate that takes knocks in stride, and complies with FDA regulations for food contact applications. Pneumatic adjustable timer opens or closes a circuit and has a timed delay before reset. No electricty to operate.
Switch rating 10 amps @ 240 VAC resistive and has a timer range: 2 - 60 seconds (± 15%). Indoor use only. Not recommended for outdoor/water applications, temperature range of button 15° to 120°F (-9° to +49°C).
Timer life of over 1,000,000 operations. Ideal for security applications. 1 Form Z, 1 N.O. and 1 N.C. contact.
ADA Compliant, UL/cUL Listed.
Key features
- Protective UV-stabilised polycarbonate cover
- Deters false alarms
- Label text – IN CASE OF FIRE – LIFT COVER / ACTIVATE FIRE ALARM
- Without sounder
- Surface mount (50mm clear spacer) with gasket
- UL/cUL Listed
- Vertical installation recommended
- 137 mm H x 127 mm W x 131 mm D
If you are matching this to an existing installation, work from the STI-3150 part number rather than the description.
Specifications
General information
Technical information
Certifications
Physical characteristics
Product information
Miscellaneous
Attributes
Specifications
| Brand Name | Safety Technology International |
|---|---|
| Manufacturer Part Number | STI-3150 |
| Product Series | STI-1100 |
| Product Type | Security Cover |
General information
| Application/Usage | Building, College, Hospital, Hotel, Nursing Home, School, Store |
|---|
Technical information
| Device Supported | Alarm System |
|---|
Certifications
| Certifications & Standards | UL/cUL Listed, IP Rating 44 ADA Compliant |
|---|
Physical characteristics
| Colour | Clear |
|---|---|
| Depth | 132.00mm |
| Form Factor | Surface Mount |
| Height | 157.00mm |
| Material | Polycarbonate |
| Width | 127.00mm |
Product information
| Mount Type | Surface Mount |
|---|
Miscellaneous
| Additional Information | Country of origin: United States. Country of origin is subject to change. |
|---|---|
| Features | Deters false alarms, Surface Mount, Without sounder |
| Indoor or outdoor use | Indoor, Outdoor |
Attributes
| Device Supported | Alarm System |
|---|---|
| Package Contents | Weather Stopper without Horn with Spacer Fire Label; Clear Spacer with Gasket |
