Sangamo CHOICE RSTAT5RF Wireless Digital Programmable Thermostat
£
91
73
(Incl. VAT)
3 Years Warranty
Wireless Digital Programmable Thermostat
About this product
About this product
The Sangamo CHOICE RSTAT5RF is a wireless digital programmable thermostat for heating control, with comfort and economy operation, 24 hour or 7 day programming and 6 programmable events per day. It transmits at 868 MHz, has a unique RF address and has frost protection.
Key features
- Wireless digital programmable thermostat
- Comfort and economy operation
- 24 hour or 7 day programmable, 6 programmable events per day
- 868 MHz, 80 m open field wireless range
- Unique RF address to avoid interference
- Frost protection
- Button press back-lit operation
- SPDT volt-free output (NO, COM & NC)
Frequently asked questions
Is the CHOICE RSTAT5RF wireless?
Yes. It communicates at 868 MHz with an 80 m open field range.
How many events can be programmed?
6 programmable events per day, on a 24 hour or 7 day schedule.
Does it have frost protection?
Yes.
How is the thermostat powered?
6 V DC from 4 x AAA batteries.
Can it be free standing?
Yes. It can be surface mounted or free standing.
-
Download
- CHOICE RSTAT5RF Tech Sheet
£
91
73
FAST delivery by Order within
Price
Technical Details
Specifications
Wireless Thermostat Receiver
1
Colour
White
Receiver dimensions (mm)
88 x 88 x 39.4
Thermostat transmitter dimensions (mm)
110 x 104 x 21.5
Materials
ABS
Mounting
Surface
Call for Heat Indication
LCD Display
Supply Voltage (V AC)
230
Cable Size (mm²)
0.5- 1.5 (Flex)
Adjustment Type
Comfort / Economy
Transmission Frequency (MHz)
868
Schedule
24 Hour or 7 Days
Wireless Range - Open Field (m)
80
Set Temperature Range (°C)
0 to 50
Wireless Range - Indoor (m)
30
Temperature Display Range (°C)
5 to 35
Relay Rating
16A (@250V AC) Volt Free Contact
Temperature Swing Adjustment (°C)
+/-05 or +0/-0.1 (Selectable)
IEC Protection Class
II
Minimum Interval (Mins)
10
Timing Accuracy
<1 sec Per Day
Operating Temperature (°C)
0 to +50
Frost Protection
Yes (5°C)
Warranty Years
3
Dimensions
Thermostat transmitter (mm)
110 x 104 x 21.5
Receiver (mm)
88 x 88 x 39.4
Specifications
| Wireless Thermostat Receiver | 1 |
|---|---|
| Colour | White |
| Receiver dimensions (mm) | 88 x 88 x 39.4 |
| Thermostat transmitter dimensions (mm) | 110 x 104 x 21.5 |
| Materials | ABS |
| Mounting | Surface |
| Call for Heat Indication | LCD Display |
| Supply Voltage (V AC) | 230 |
| Cable Size (mm²) | 0.5- 1.5 (Flex) |
| Adjustment Type | Comfort / Economy |
| Transmission Frequency (MHz) | 868 |
| Schedule | 24 Hour or 7 Days |
| Wireless Range - Open Field (m) | 80 |
| Set Temperature Range (°C) | 0 to 50 |
| Wireless Range - Indoor (m) | 30 |
| Temperature Display Range (°C) | 5 to 35 |
| Relay Rating | 16A (@250V AC) Volt Free Contact |
| Temperature Swing Adjustment (°C) | +/-05 or +0/-0.1 (Selectable) |
| IEC Protection Class | II |
| Minimum Interval (Mins) | 10 |
| Timing Accuracy | <1 sec Per Day |
| Operating Temperature (°C) | 0 to +50 |
| Frost Protection | Yes (5°C) |
| Warranty Years | 3 |
Dimensions
| Thermostat transmitter (mm) | 110 x 104 x 21.5 |
|---|---|
| Receiver (mm) | 88 x 88 x 39.4 |
Wireless Digital Programmable Thermostat features
Sangamo CHOICE RSTAT5RF Wireless Digital Programmable Thermostat
