Sangamo S254.2 3 Pin Time Switch, 2 On/Offs, black dial, no battery reserve
Free Delivery
£
179
72
(Incl. VAT)
3 Pin Time Switch, 2 On/Offs, black dial, no battery reserve
About this product
About this product
The Sangamo S254.2 is a standard 3 pin time switch from Sangamo's range of time switches, giving 2 ON/OFF periods on a 24 hour dial. Its single SPST switched-live output is rated 20A resistive at 230 V AC, and it has a manual override button and day omission.
Key features
- Standard 3 pin base, surface mounting
- 24 hour dial with 2 ON/OFF periods, calibrated in 15 minute divisions
- 1 SPST switched-live output, 20A resistive at 230 V AC
- Temporary override by manual button
- Day omission: skips the ON operation
- Quartz time base, accurate to 5 minutes a year
- No power reserve; Class I, must be earthed
Frequently asked questions
How many switching periods does the S254.2 have?
2 ON/OFF periods on a 24 hour programme, set on a dial calibrated in 15 minute divisions.
What load can the S254.2 switch?
Its SPST output is rated 20A resistive at 230 V AC, with load ratings of 3600 W for incandescent or halogen lamps and 3600 W for LED at 230V.
Does the S254.2 have a power reserve?
No. It has no power reserve.
Can the S254.2 skip a day?
Yes. Day omission omits the ON operation.
Does the S254.2 need an earth?
Yes. It is Class I and must be earthed.
-
Download
- S254.2 Tech Sheet
£
179
72
FAST delivery by Order within
Price
Technical Details
Specifications
Number of Outputs
1
Display
24 Hour Dial
Relay/Contact Type
SPST
Timing Accuracy
5 Minutes / Year
Relay Voltage - Maximum (AC)
230
Time Base
Quartz Crystal
Relay Resistive Load Rating (A)
20
Mounting
Surface Mounting
Base Type
3 Pin
Available Operations
2 ON/OFF Periods
Dial Calibration
15 Minute Divisions
Maximum Fluorescent Lamp Load Rating
1980
Day Omission
Yes (omits the "ON" operation)
Supply Voltage (V AC)
230
Power Consumption (W)
0.6
Cable Size (mm²)
0.5 - 4
Power Reserve
None
IEC Protection Class
Class I (Must be Earthed)
Operating Temperature (°C)
0 to +50
Dimensions (mm)
146.5 x 105.7 x 82
Maximum LED Lamp Load Rating (W)
3600 @ 230V
Maximum Discharge (Sodium, Mercury, Metal Halide) Lamp Load Rating (W)
3600
Maximum Inductive Current Rating (A) (0.6pf)
5
Maximum Inductive Current Rating (A) (0.8pf)
12
Maximum Incandescent, Halogen Lamp Load Rating (W)
3600
Minimum Period Between Like Operations (Hours)
1.75
Minimum Period Between Unlike Operations (Mins)
15
Programming Schedule
24 Hour Program
Setting Accuracy
+/- 3 Minutes
Ingress Protection
IP20
Output Type
3 Pin; SPST, Switched Live
Total Switch Rating
20A
Materials
Base: Polycarbonate 940 Black; Cover: Idemitsu Polycarbonate
Specifications
| Number of Outputs | 1 |
|---|---|
| Display | 24 Hour Dial |
| Relay/Contact Type | SPST |
| Timing Accuracy | 5 Minutes / Year |
| Relay Voltage - Maximum (AC) | 230 |
| Time Base | Quartz Crystal |
| Relay Resistive Load Rating (A) | 20 |
| Mounting | Surface Mounting |
| Base Type | 3 Pin |
| Available Operations | 2 ON/OFF Periods |
| Dial Calibration | 15 Minute Divisions |
| Maximum Fluorescent Lamp Load Rating | 1980 |
| Day Omission | Yes (omits the "ON" operation) |
| Supply Voltage (V AC) | 230 |
| Power Consumption (W) | 0.6 |
| Cable Size (mm²) | 0.5 - 4 |
| Power Reserve | None |
| IEC Protection Class | Class I (Must be Earthed) |
| Operating Temperature (°C) | 0 to +50 |
| Dimensions (mm) | 146.5 x 105.7 x 82 |
| Maximum LED Lamp Load Rating (W) | 3600 @ 230V |
| Maximum Discharge (Sodium, Mercury, Metal Halide) Lamp Load Rating (W) | 3600 |
| Maximum Inductive Current Rating (A) (0.6pf) | 5 |
| Maximum Inductive Current Rating (A) (0.8pf) | 12 |
| Maximum Incandescent, Halogen Lamp Load Rating (W) | 3600 |
| Minimum Period Between Like Operations (Hours) | 1.75 |
| Minimum Period Between Unlike Operations (Mins) | 15 |
| Programming Schedule | 24 Hour Program |
| Setting Accuracy | +/- 3 Minutes |
| Ingress Protection | IP20 |
| Output Type | 3 Pin; SPST, Switched Live |
| Total Switch Rating | 20A |
| Materials | Base: Polycarbonate 940 Black; Cover: Idemitsu Polycarbonate |
