Sangamo SC4411PRO4 Bluetooth 1 Channel 7 Day Digital Panel Timer
£
81
50
(Incl. VAT)
3 Years Warranty
Bluetooth 1 Channel 7 Day Digital Panel Timer
About this product
About this product
The Sangamo SC4411PRO4 is an astro Bluetooth 1 channel 7 day digital panel timer, programmable via app (iOS, Android and Windows). It has a volt-free 16A changeover contact, holds 300 operations and comes ready for panel or surface mounting.
Key features
- Astro, 24 hour and 7 day programmable; Bluetooth
- Programmable via app (iOS, Android and Windows)
- 300 operations; switching modes ON, OFF, pulse, cycle, extra, permanent and astro
- 1 SPDT output: a volt-free 16A changeover contact
- Total switch rating 16A @ 1.0pf resistive (230V AC), 10A @ 0.6pf inductive
- Maximum LED lamp load 200 W @ 230V
- Panel or surface mounting: 72 x 72 mm panel size, retaining clip in a 68 x 68 cutout
- Backlit LCD display; power reserve 10 years (approx.)
Frequently asked questions
Is the SC4411PRO4 programmable via an app?
Yes, via app (iOS, Android and Windows).
How many operations does it hold?
300 operations.
How is it mounted?
It comes ready for panel or surface mounting; it fits a 68 x 68 cutout with a retaining clip.
What can it switch?
Its volt-free 16A changeover contact has a total switch rating of 16A @ 1.0pf resistive (230V AC) and 10A @ 0.6pf inductive, with a maximum LED lamp load of 200 W @ 230V.
What is its power reserve?
10 years (approx.).
-
Download
- SC4411PRO4 Tech Sheet
£
81
50
FAST delivery by Order within
Price
Technical Details
Specifications
Dimensions (mm)
94.5 x 72 x 53
Number of Outputs
1
Panel Dimensions (mm)
72 x 72
Relay/Contact Type
SPDT
Display
Backlit-LCD Display
Total Switch Rating (Inductive)
10A @ 0.6pf
Time Base
Quartz Crystal
Total Switch Rating (Resistive)
230V AC, 16A @ 1.0pf
Quartz Crystal Accuracy (at 20°C)
≤ ± 0.5 Seconds / Day
Maximum LED Lamp Load Rating (W)
200 @ 230V
Materials
Self-Extinguishing Thermoplastic
Contact Material
AgSnO²
Mounting
Surface or Panel
Warranty (Years)
3
Maximum Starting Current Rating (A)
50
Bluetooth
Yes
Available Operations
300 Operations
Switching Modes
ON, OFF, Pulse, Cycle, Extra, Permanent, Astro
Minimum Switching power (mW)
1000 (10V/10mA)
Program Security
Unlimited (E2-PROM)
Pulse length - Timer (man. switching)
0:00:01 up to 9:59:59 h:mm:ss
Supply Voltage (V AC)
230
Power Consumption (W)
0.2-1
Power Reserve
10 Years (Approx.)
IEC Protection Class
Class II When Installed According to Regulations
Operating Temperature (°C)
-30 to +55
Maximum Incandescent, Halogen Lamp Load Rating (W)
2000
Maximum Fluorescent Lamp (Uncompensated) Load Rating (W)
1000
Maximum Fluorescent Lamp (Series Compensated) Load Rating (W)
1000
Maximum Fluorescent Lamp (Parallel Compensated) Load Rating (W)
550
Programming Schedule
Astro, 24 Hour, and 7 Day Programmable
Minimum Interval (Between 2 Switchings)
1 Minute
Switchboard Flush Dimensions (mm)
Retaining clip in 68 x 68 cutout
Pulse length - Pulse function (switching time)
00:01 up to 59.59 mm:ss
Ingress Protection
IP20
Dimensions
Dimensions (mm)
94.5 x 72 x 53
Specifications
| Dimensions (mm) | 94.5 x 72 x 53 |
|---|---|
| Number of Outputs | 1 |
| Panel Dimensions (mm) | 72 x 72 |
| Relay/Contact Type | SPDT |
| Display | Backlit-LCD Display |
| Total Switch Rating (Inductive) | 10A @ 0.6pf |
| Time Base | Quartz Crystal |
| Total Switch Rating (Resistive) | 230V AC, 16A @ 1.0pf |
| Quartz Crystal Accuracy (at 20°C) | ≤ ± 0.5 Seconds / Day |
| Maximum LED Lamp Load Rating (W) | 200 @ 230V |
| Materials | Self-Extinguishing Thermoplastic |
| Contact Material | AgSnO² |
| Mounting | Surface or Panel |
| Warranty (Years) | 3 |
| Maximum Starting Current Rating (A) | 50 |
| Bluetooth | Yes |
| Available Operations | 300 Operations |
| Switching Modes | ON, OFF, Pulse, Cycle, Extra, Permanent, Astro |
| Minimum Switching power (mW) | 1000 (10V/10mA) |
| Program Security | Unlimited (E2-PROM) |
| Pulse length - Timer (man. switching) | 0:00:01 up to 9:59:59 h:mm:ss |
| Supply Voltage (V AC) | 230 |
| Power Consumption (W) | 0.2-1 |
| Power Reserve | 10 Years (Approx.) |
| IEC Protection Class | Class II When Installed According to Regulations |
| Operating Temperature (°C) | -30 to +55 |
| Maximum Incandescent, Halogen Lamp Load Rating (W) | 2000 |
| Maximum Fluorescent Lamp (Uncompensated) Load Rating (W) | 1000 |
| Maximum Fluorescent Lamp (Series Compensated) Load Rating (W) | 1000 |
| Maximum Fluorescent Lamp (Parallel Compensated) Load Rating (W) | 550 |
| Programming Schedule | Astro, 24 Hour, and 7 Day Programmable |
| Minimum Interval (Between 2 Switchings) | 1 Minute |
| Switchboard Flush Dimensions (mm) | Retaining clip in 68 x 68 cutout |
| Pulse length - Pulse function (switching time) | 00:01 up to 59.59 mm:ss |
| Ingress Protection | IP20 |
Dimensions
| Dimensions (mm) | 94.5 x 72 x 53 |
|---|
