Scope RX2LOG pocsag logging receiver
About this product
Please note: this is a non-returnable item (excluding faulty goods)
Scope RX2LOG is a pocsag logging receiver.
RX2 Mk2 has 22 zones with relay outputs, an RS232 output and a USB port for programming. There is also a microSD slot with an 8GB card for recording event log data. The card also contains the programming software, enabling complete control of the unit’s configuration from a PC and for downloading and analysing the data contained in the log.
It is also possible to monitor live incoming data in text and graphical formats.
Key features
- Receives monitors and logs POCSAG data
- 2-Zone relay outputs RS232 output USB programming port
- MicroSD slot for event logging
- PC software supplied
- High quality category 1.5 receiver module EN 300 220-1 v3.1
- Frequency range of 430MHz to 470MHz
- Power requirement is 12-13.8VDC maximum current draw is 126mA
If you are matching this to an existing installation, work from the RX2LOG part number rather than the description.
Specifications
Specifications
| Brand Name | Scope |
|---|---|
| Manufacturer Part Number | RX2LOG |
| Product Type | Receiver |
