Securi-Flex SFX/5304FE-LSZH-D-BLU-100 6 Core 18AWG Overall Foil Screened Cable, Blue LSZH, 100m
Free Delivery
£
211
25
(Incl. VAT)
About this product
Please note: this is a non-returnable item (excluding faulty goods)
The Securi-Flex SFX/5304FE-LSZH-D-BLU-100 is an 18AWG Belden equivalent cable (5304FE) with bare copper conductors, PP insulation and a blue LSZH sheath, rated 300V, for security, intercom/PA, audio/speaker and power limited controls installations. Supplied as a 100 m length.
Key features
- Belden equivalent cable (5304FE), 18AWG
- For security, intercom/PA, audio/speaker and power limited controls installations
- Bare copper conductors with PP insulation; insulation colours black, white, red, green, brown and blue
- Blue LSZH overall sheath; CPR class Dca -s:2 -a:1 -d:2
- Max conductor DC resistance at 20°C less than 21.10 Ω/km; rated voltage 300V
- 100 m length; 6 conductors
Frequently asked questions
What is it used for?
Security, intercom/PA, audio/speaker and power limited controls installations.
How many conductors does it have?
6, insulated in black, white, red, green, brown and blue.
What is its CPR class?
Dca -s:2 -a:1 -d:2, with an LSZH overall sheath.
What voltage is it rated for?
300V.
How long is it?
100 m.
£
211
25
Price
Technical Details
Specifications
Brand Name
Securi-Flex
Manufacturer Part Number
SFX/5304FE-LSZH-D-BLU-100
Belden Equivalent
5304FE
Conductor Size
18AWG
Application
For security, intercom/PA, audio/speaker, power limited controls installations.
Overall Colour
Blue
Overall Sheath
LSZH
Standards
CE2014/30/EU, RoHS2 2011/65/EU, LVD 2014/35/EU
CPR
Dca -s:2 -a:1 -d:2
Conductor
Bare Copper
Insulation Colour
Black, White, Red, Green, Brown, Blue
Insulation
PP
Max Conductor DC resistance @ 20°C
<21.10 Ω/km
Rated Voltage (V)
300V
Technical information
Conductor Count
6
Physical characteristics
Cable Length
100.00m
Specifications
| Brand Name | Securi-Flex |
|---|---|
| Manufacturer Part Number | SFX/5304FE-LSZH-D-BLU-100 |
| Belden Equivalent | 5304FE |
| Conductor Size | 18AWG |
| Application | For security, intercom/PA, audio/speaker, power limited controls installations. |
| Overall Colour | Blue |
| Overall Sheath | LSZH |
| Standards | CE2014/30/EU, RoHS2 2011/65/EU, LVD 2014/35/EU |
| CPR | Dca -s:2 -a:1 -d:2 |
| Conductor | Bare Copper |
| Insulation Colour | Black, White, Red, Green, Brown, Blue |
| Insulation | PP |
| Max Conductor DC resistance @ 20°C | <21.10 Ω/km |
| Rated Voltage (V) | 300V |
Technical information
| Conductor Count | 6 |
|---|
Physical characteristics
| Cable Length | 100.00m |
|---|
Securi-Flex SFX/5304FE-LSZH-D-BLU-100 6 Core 18AWG Overall Foil Screened Cable, Blue LSZH, 100m
