Securi-Flex SFX/C6-UTP-PE-BLK-500 data cable, 500m
Free Delivery
£
289
01
(Incl. VAT)
About this product
Please note: this is a non-returnable item (excluding faulty goods)
The Securi-Flex SFX/C6-UTP-PE-BLK-500 is a Category 6 data cable with 4 pairs UTP and a black polyethylene (PE) outer sheath, for external data transmission up to 1Gb/s (10Gb/s up to 37 m). This item is a 500 m length.
Key features
- Category 6 data cable, 4 pairs UTP
- Black PE (polyethylene) outer sheath, Black RAL 9005
- Application: external data transmission up to 1Gb/s (10Gb/s up to 37 m)
- Bare copper conductors with HDPE insulation; coloured core identification
- CPR class Fca
- Max conductor DC resistance below 95 Ω/km at 20 °C
- Standards: ISO/IEC 11801, ANSI/TIA 568-C.2, CE 2014/30/EU, LVD 2014/35/EU, RoHS2 2011/65/EU
- 500 m length
Frequently asked questions
What speed is it for?
External data transmission up to 1Gb/s, and 10Gb/s up to 37 m.
What is the outer sheath?
Polyethylene (PE), Black RAL 9005.
What are the conductors and insulation?
Bare copper conductors with HDPE insulation, in 4 pairs with coloured core identification.
What is its CPR class?
Fca.
How long is it?
500 m.
£
289
01
Price
Technical Details
Specifications
Brand Name
Securi-Flex
Manufacturer Part Number
SFX/C6-UTP-PE-BLK-500
Product Type
Category 6 Network Cable
Application
External data transmission up to 1Gb/s (10Gb/s up to 37 m)
Outer Sheath
PE (Polyethylene), Black RAL 9005
Conductor
Bare Copper
Insulation
HDPE
Core Colours
Blue/White/Blue; Orange/White/Orange; Green/White/Green; Brown/White/Brown
CPR
Fca
Max Conductor DC Resistance @ 20°C
<95 Ω/km
Standards
ISO/IEC 11801, ANSI/TIA 568-C.2, CE2014/30/EU, LVD 2014/35/EU, RoHS2 2011/65/EU
Technical information
Cable Type
Cat6 Network
Conductor Count
8
Physical characteristics
Cable Length
500.00m
Specifications
| Brand Name | Securi-Flex |
|---|---|
| Manufacturer Part Number | SFX/C6-UTP-PE-BLK-500 |
| Product Type | Category 6 Network Cable |
| Application | External data transmission up to 1Gb/s (10Gb/s up to 37 m) |
| Outer Sheath | PE (Polyethylene), Black RAL 9005 |
| Conductor | Bare Copper |
| Insulation | HDPE |
| Core Colours | Blue/White/Blue; Orange/White/Orange; Green/White/Green; Brown/White/Brown |
| CPR | Fca |
| Max Conductor DC Resistance @ 20°C | <95 Ω/km |
| Standards | ISO/IEC 11801, ANSI/TIA 568-C.2, CE2014/30/EU, LVD 2014/35/EU, RoHS2 2011/65/EU |
Technical information
| Cable Type | Cat6 Network |
|---|---|
| Conductor Count | 8 |
Physical characteristics
| Cable Length | 500.00m |
|---|
