Securi-Flex SFX/USC4-22-LSZH-D-GRY-100 2 Pair 22AWG Unscreened Data Cable, Grey, 100m
£
60
07
(Incl. VAT)
About this product
Please note: this is a non-returnable item (excluding faulty goods)
The Securi-Flex SFX/USC4-22-LSZH-D-GRY-100 is a 2-pair, 22AWG unscreened pair data cable with tinned copper conductors, LSZH insulation and a grey LSZH sheath, rated 600V, for control, instrumentation, audio and panel wiring. Supplied as a 100 m length.
Key features
- 2 pairs, 22AWG, unscreened pairs
- For control, instrumentation, audio and panel wiring
- Tinned copper conductors with LSZH insulation; insulation colours black, red, white and green
- Grey LSZH overall sheath; CPR class Dca -s:2 -a:1 -d:2
- Max conductor DC resistance at 20°C 57.00 Ω/km; rated voltage 600V
- 100 m length; 4 conductors
Frequently asked questions
How many pairs does it have?
2 unscreened pairs of 22AWG conductors (4 conductors).
What is it used for?
Control, instrumentation, audio and panel wiring.
What is its CPR class?
Dca -s:2 -a:1 -d:2, with an LSZH overall sheath.
What are the core colours?
Black, red, white and green.
How long is it?
100 m.
£
60
07
Price
Technical Details
Specifications
Brand Name
Securi-Flex
Manufacturer Part Number
SFX/USC4-22-LSZH-D-GRY-100
Product Name
Dali Equivalent Cable USC4-22 2 Pairs 22AWG Unscreened Pair Data 600V DCA LSZH (8444) - Grey
Pairs
2
Conductor Size
22AWG
Screen
Unscreened Pair
Application
For control, instrumentation, audio and panel wiring.
Overall Colour
Grey
Overall Sheath
LSZH
Standards
CE2014/30/EU, RoHS2 2011/65/EU, LVD 2014/35/EU
CPR
Dca -s:2 -a:1 -d:2
Conductor
Tinned Copper
Insulation Colour
Black, Red, White, Green
Insulation
LSZH
Max Conductor DC resistance @ 20°C
57.00 Ω/km
Rated Voltage (V)
600V
Technical information
Conductor Count
4
Physical characteristics
Cable Length
100.00m
Specifications
| Brand Name | Securi-Flex |
|---|---|
| Manufacturer Part Number | SFX/USC4-22-LSZH-D-GRY-100 |
| Product Name | Dali Equivalent Cable USC4-22 2 Pairs 22AWG Unscreened Pair Data 600V DCA LSZH (8444) - Grey |
| Pairs | 2 |
| Conductor Size | 22AWG |
| Screen | Unscreened Pair |
| Application | For control, instrumentation, audio and panel wiring. |
| Overall Colour | Grey |
| Overall Sheath | LSZH |
| Standards | CE2014/30/EU, RoHS2 2011/65/EU, LVD 2014/35/EU |
| CPR | Dca -s:2 -a:1 -d:2 |
| Conductor | Tinned Copper |
| Insulation Colour | Black, Red, White, Green |
| Insulation | LSZH |
| Max Conductor DC resistance @ 20°C | 57.00 Ω/km |
| Rated Voltage (V) | 600V |
Technical information
| Conductor Count | 4 |
|---|
Physical characteristics
| Cable Length | 100.00m |
|---|
