Texecom GCD-0001 alarm control panel zone controller, White

£ 86 03
(Incl. VAT)

About this product

The Texecom Premier Elite 8XP-W is an 8 zone wireless expander, so it suits alarm installers adding Ricochet wireless devices to a Premier panel. It connects to the panel's network over 4-wire cable and needs compatible panel firmware. It is a receiver, not a detector, so detectors are extra.

Key features

  • Adds wireless to a wired panel – 8 wireless zones
  • Longer reach through a building – Ricochet mesh, with devices relaying for each other
  • Reroutes itself – the mesh self-heals if a link weakens
  • Long cable runs to the panel – up to 250m on 4-wire 7/0.2 alarm cable
  • Diagnostics – works with Ricochet Monitor software through its comms port
  • Certified to security grade 2, environmental class II

For installers

  • Power: 10 - 13.7VDC from the panel network, current under 120mA.
  • Mounting: at least two countersunk screws, no larger than No. 8. Keyhole slot, rear tamper knockout.
  • Cabling: + - T R, 4-wire standard 7/0.2 alarm cable up to 250m. Star, daisy chain or any combination.
  • Compatibility: Premier panels at the firmware Texecom lists, except the 816E (not supported). Ricochet is not released for the Premier 640. Earlier firmware is not compatible. Check Premier Elite firmware in the panel's own documentation.
  • Network address: set by DIL switches, factory set to address 1.
  • Standards: security grade 2, environmental class II (INCERT C-026-1344/a).

Frequently asked questions

Is this a detector?

No. It is the wireless receiver that connects to the panel. Detectors and contacts are extra.

How many wireless zones does it add?

8 zones. Texecom's 32XP-W is the larger version.

Will it work with my panel?

Check the firmware first. Texecom's manual says earlier firmware than its table is not compatible and some functions depend on the version. It marks the Premier 816E as not supported and shows Ricochet as not released for the Premier 640. The table does not name Premier Elite models, so check the panel's own documentation.

Does it need its own power supply?

Not in the manual's wiring, which takes 10 - 13.7VDC from the panel network, at under 120mA.

What cable does it use?

4-wire standard 7/0.2 alarm cable, up to 250m. Texecom says screened cable may be needed in certain conditions.

£ 86 03
Google Top Quality Store · Rated Exceptional
Ships from United Kingdom
28 days hassle free returns
Secure payment transactions
Price
£86.03 Incl. VAT
Add a WME Product Care Plan Includes warranty, replacement and repairs backed by WME
Why add a product care plan:
  • Full breakdown support
  • Full replacement if we can't repair your product within 10 days
  • All parts, labour and callouts included if necessary
  • Extended manufacturer warranty with faster turn arounds
  • Excludes accidental & cosmetic damages
By selecting one of these plans you agree to purchase WME Care Plan. Please read the Terms and Important information to ensure WME Care Plan is right for you. Compare prices of extended warranties for electrical goods at www.compareextendedwarranties.co.uk
WME Care
Technical Details
Specifications
Brand
Texecom
Model
Premier Elite 8XP-W
Manufacturer Part Number (MPN)
GCD-0001
Also listed as
8XP-W
Product type
Wireless zone expander
Product series
Ricochet
Wireless zones
8
Operating voltage
10 - 13.7VDC
Current consumption
<120mA
Network
4-wire standard 7/0.2 alarm cable up to 250m. Star, Daisy Chain or any combination
Outputs 1 - 8
Not used
Operating temperature
-10°C to +50°C
Storage temperature
-20°C to +60°C
Maximum humidity
95% non-condensing
Security grade
Grade 2
Environmental class
Class II
INCERT certificate
C-026-1344/a
Technical information
Connectivity Technology
Wired, Wireless
Certifications
INCERT Certified
Yes
Security Grade
Grade 2
Physical characteristics
Colour
White
Height
35.00mm
Width
120.00mm
Product information
Length
120.00mm
Miscellaneous
Additional Information
Wireless Monitor Software Diagnostics Engineers Keypad Connectivity Suitable for Commercial Applications Grade 2 Class II
Attributes
Compatibility
Texecom Premier Elite Control Panels

Specifications

Brand Texecom
Model Premier Elite 8XP-W
Manufacturer Part Number (MPN) GCD-0001
Also listed as 8XP-W
Product type Wireless zone expander
Product series Ricochet
Wireless zones 8
Operating voltage 10 - 13.7VDC
Current consumption <120mA
Network 4-wire standard 7/0.2 alarm cable up to 250m. Star, Daisy Chain or any combination
Outputs 1 - 8 Not used
Operating temperature -10°C to +50°C
Storage temperature -20°C to +60°C
Maximum humidity 95% non-condensing
Security grade Grade 2
Environmental class Class II
INCERT certificate C-026-1344/a

Technical information

Connectivity Technology Wired, Wireless

Certifications

INCERT Certified Yes
Security Grade Grade 2

Physical characteristics

Colour White
Height 35.00mm
Width 120.00mm

Product information

Length 120.00mm

Miscellaneous

Additional Information Wireless Monitor Software Diagnostics Engineers Keypad Connectivity Suitable for Commercial Applications Grade 2 Class II

Attributes

Compatibility Texecom Premier Elite Control Panels

Texecom GCD-0001 alarm control panel zone controller

Texecom GCD-0001 alarm control panel zone controller, White

What this wireless expander is for

Running cable to every detector is not always practical. This Texecom Ricochet expander is a receiver that joins a Premier panel's network and adds 8 wireless zones.

It suits alarm installers adding wireless detectors to a wired panel, where running cable to a room would be slow or disruptive. It is not a detector, so the detectors and contacts are extra, and they need to be Ricochet models for Ricochet operation.

How does a Ricochet expander work?

The expander wires back to the panel on its data network, then speaks to its wireless devices by radio.

  • Ricochet mesh: every wireless device can receive and pass on signals from the others. A device that cannot reach the expander directly can relay through its neighbours.
  • Self-healing: if a link weakens, the network reroutes through another Ricochet device. Texecom says reliability rises as more devices are installed.
  • Hops: a signal can pass through up to two other devices, for a maximum of three hops. Texecom advises avoiding long, thin layouts.
  • Legacy mode: an option switch selects Ricochet or Legacy operation. Which one you can use depends on the panel's firmware.

Where to use it

Fit it indoors, in line with its class II rating. It works from -10°C to +50°C and up to 95% non-condensing humidity. Texecom lists no IP rating in this manual.

Texecom asks for devices to be placed working outwards from the expander, with the closest going in first and the furthest last.

What the figures mean in practice

  • 8 zones: a zone is one monitored point, usually a detector or contact. Check the panel has spare zones for them.
  • Under 120mA: add this to the panel's network current along with everything else on that supply.
  • Up to 250m: this is the network run on 4-wire standard 7/0.2 alarm cable, wired as a star, a daisy chain or a mix of the two.
  • 10 to 13.7VDC: power comes over the panel network, so no separate supply is called for in the manual's wiring. On a long run, voltage drop can take you towards the lower limit.

Installing it

  • Before you start: Texecom strongly recommends powering the system down, mains and battery, before wiring the expander.
  • Fixing: use at least two countersunk screws, no larger than No. 8. A keyhole slot helps with levelling, and a screw through the rear knockout enables the wall tamper.
  • Wiring: connect +, -, T and R to the matching panel or previous device terminals. Spare cores in 6 or 8-core cable can double up the power connections.
  • Address: set a different address on each expander with the DIL switches. It leaves the factory on address 1, and two expanders on one network must never share an address.
  • Learning devices: learn every device before placing it, keeping it at least 30cm from the receiver.
  • Testing: wait at least 15 minutes after placing the last device so routing can settle, then walk test the system.

Planning your system

Check the firmware first. Texecom says earlier firmware than its table lists will not work, and some functions depend on the version.

The manual's table covers older Premier panels and does not name Premier Elite models. It marks the Premier 816E as not supported, and shows Ricochet as not released for the Premier 640. Texecom's Premier Elite range brochure lists the 8XP-W among its expansion modules, so confirm the version with your panel's own documentation.

The figures on this page come from Texecom's 2010 manual for the Premier 8XP-W, which does not use the Elite name, while the certificate lists later hardware. Check Texecom's current documentation for your unit.

For more wireless zones in one unit, Texecom also makes the 32XP-W.

Standards explained

  • Security grade 2: the INCERT certificate says this equipment can be applied in EN 50131-1 systems up to and including grade 2, which means low to medium risk.
  • Environmental class II: the certificate's class for this equipment, and EN 50131 class II is intended for indoor use.
  • INCERT: an approval scheme for alarm equipment. The certificate lists the 8XP-W as type GCDA1000-3.
