TRENDnet TI-OS300 ethernet surge protector
About this product
TRENDnet TI-OS300 is an ethernet surge protector.
The TRENDnet TI-OS300 Outdoor 2.5G PoE++ Ethernet Surge Protector is designed to safeguard network connections with two 2.5Gbps RJ45 Ethernet ports and a ground terminal. It supports PoE (15.4W), PoE+ (30W), and PoE++ (up to 95W) devices, operating reliably in temperatures ranging from -40° to 75° C (-40° to 167° F). The IP67-rated metal enclosure and Ethernet cable glands provide robust protection against environmental factors.
The surge protector features line to line and line to ground protection modes, gas discharge tube (GDT) protection with a nominal discharge current of 10kA, and meets IEC 61643-21 and IEC 61000-4-5 standards. Its compact design includes a detachable mounting bracket, and it is NDAA / TAA compliant for use in the U.S. and Canada.
Key features
- Two 2.5Gbps RJ45 Ethernet ports and ground terminal
- Supports PoE (15.4W), PoE+ (30W), and PoE++ (up to 95W) devices
- Operating temperature range of -40°– 75° C (-40° – 167° F)
- IP67-rated metal enclosure and Ethernet cable glands
- Line to line and line to ground protection modes
- Gas discharge tube (GDT) protection with a nominal discharge current (8/20s) of 10kA and clamping voltage of 20V at 1kA
- Compliant with shock, freefall, vibration, IEC 61643-21, and IEC 61000-4-5 standards
- Compact design with detachable mounting bracket
- NDAA / TAA compliant (U.S. and Canada only)
If you are matching this to an existing installation, work from the TI-OS300 part number rather than the description.
Specifications
Specifications
| Brand Name | TRENDnet |
|---|---|
| Manufacturer Part Number | TI-OS300 |
