Vanco ICA6-B in-ceiling angled speaker, In-ceiling
About this product
Please note: this is a non-returnable item (excluding faulty goods)
Vanco ICA6-B is an in-ceiling angled speaker.
Innovative speaker design that produces great sound in a patented enclosure. Sound bleed to adjacent rooms is eliminated by redirecting driver backside air compression. Given this redirected airflow, there is virtually no transfer of energy from the driver to the enclosure.
This not only improves audio performance but also simplifies installation by eliminating the need for a backbox. Potential for drywall cracking from low-frequency vibration is also eliminated and removes the need for additional bracing, even with subwoofers. Sonic Vortex speakers assure consistent performance in stereo and multi-channel systems by removing the potentially adverse affects of uneven wall and ceiling cavities.
Key features
- 6.5" Poly In-Ceiling Angled Speaker
- 1" Silk Dome Tweeter for Clear Sound
- Innovative Design with Patented Enclosure
- Eliminates Sound Bleed to Adjacent Rooms
- No Need for Backbox, Simplifies Installation
- Prevents Drywall Cracking from Vibration
- Consistent Performance in Stereo Systems
If you are matching this to an existing installation, work from the ICA6-B part number rather than the description.
Specifications
Technical information
Audio
Certifications
Environmental conditions
Physical characteristics
Product information
Attributes
Specifications
| Brand Name | Vanco |
|---|---|
| Manufacturer Part Number | ICA6-B |
| Product Type | In-Ceiling Angled Speaker |
Technical information
| Crossover Type | 2-Way |
|---|---|
| Impedance | 8Ohm |
| Sensitivity | 89dB |
| Speaker Size | 165.10mm |
| Wireless Speaker | No |
Audio
| Maximum Frequency Response | 22kHz |
|---|---|
| Minimum Frequency Response | 46Hz |
| RMS Output Power | 5W |
Certifications
| RoHS compliance | Out of Scope |
|---|---|
| WEEE compliance | Out of Scope |
Environmental conditions
| Sound Emission | 9dB |
|---|
Physical characteristics
| Colour | White |
|---|---|
| Depth | 172.00mm |
| Enclosure Type | Sealed |
| Form Factor | In-ceiling |
| Material | PP |
Product information
| Diameter | 239.00mm |
|---|---|
| Mount Type | In-ceiling Mount, In-wall Mount |
Attributes
| RMS Output Power | 5W |
|---|
