Veracity VSPAN-ONE-UK is a cost display controller.
VIEWSPAN One® is a low-cost networked display controller device, ideal for reception desks, remote monitors, auxiliary displays and digital signage applications. VIEWSPAN® Range
The VIEWSPAN® range of video display controllers is designed for a wide variety of display and AV applications. They are built on dedicated hardware platforms that meet the performance and reliability requirements of video surveillance, security and AV applications. VIEWSPAN One is a compact, fanless unit, with a single HDMI output for a Full HD monitor.
Its single-screen output is intended for auxiliary video display, remote monitors and digital signage applications, including retail and emergency signage. A range of VIEWSPAN models suits different applications. All models run on the VIEWSPAN NEXUS software platform (available as a software-only licence).
VIEWSPAN Plus 6, 9 and 12 screen models offer up to nine Full HD decodes per screen, with higher densities in the VIEWSPAN Pro range. VIEWSPAN AV can be specified to suit customer requirements, including multiple direct AV capture inputs. VIEWCAST® is a screen capture software utility that generates VIEWSPAN® video streams from desktops or applications on Windows PCs.
Optimised Software
The VIEWSPAN system incorporates highly optimised VIEWSPAN NEXUS® video processing software. Combined with NEXUS, VIEWSPAN One hardware produces super-smooth video, decoding up to 9 Full HD 30FPS channels on a Full HD monitor display. See the table opposite for full decode performance at various stream resolutions.
The larger rack-mounted VIEWSPAN variants offer higher performance and multiple display outputs per unit. Setup and Configuration
A simple web browser interface is used to configure all VIEWSPAN Display Controller systems, allowing network setup, display arrangement and VMS/NVR integration settings. VIEWSPAN can be directly integrated with the VMS or integrated security management system, or can be used as an accelerator platform for the VMS display, controlling multiple VIEWSPAN units on a client through the web browser interface. Matrix View and Layout Patterns
VIEWSPAN One can be configured for any layout on the single screen. The layout can display single or multiple video channels in a flexible matrix view, single or multiple signage or graphics, or a combination of both. Screen layouts (and display sources) can be selected manually through the web interface or automatically via time schedules or triggered via networked alarms.
Video Stream Decoding
VIEWSPAN® devices can decode almost any video stream format, with the most common being H.264 and H.265 for surveillance applications, at any resolution and frame rate. A higher number of streams can be decoded and displayed simultaneously if the resolution and/or frame rate is lower. For live video display applications, it is preferable to maintain a high frame rate (25 or 30FPS) for smooth video.
Display of 1, 4 or 9 IP camera streams or a single digital graphic or video are the most typical applications for VIEWSPAN One. Input Sources
All VIEWSPAN systems can display video, graphics and data from many sources. These include AV (audio-visual) sources, IP cameras, NVR video playback, web pages, application screen capture (see VIEWCAST), encoders, digital signage, scrolling text, time and date. All of these sources can be decoded, scaled and displayed anywhere on the display screen.
Pre-loaded (i.e. locally stored) images and graphics may also be displayed for advertising, information or emergency signage applications.
Key features
- Single output for a Full HD monitor
- Decoding and display of 9 Full HD streams at 30 FPS
- For spot monitors, auxiliary displays and signage
- Display of IP cameras, web pages, signage and text
- Independent of VMS, supports multiple integrations
- Browser-based integrated management
- 10W power consumption, with PoE option included
If you are matching this to an existing installation, work from the VSPAN-ONE-UK part number rather than the description.
Specifications
Specifications
| Brand Name | Veracity |
|---|---|
| Manufacturer Part Number | VSPAN-ONE-UK |
