Videx 2206A block exchange device
About this product
Please note: this is a non-returnable item (excluding faulty goods)
Videx 2206A is a block exchange device.
A range of VX2200 system entrance switching devices for both audio and video systems-VX123A / VX123V, 4 door audio and video switching PCBs respectively. Both versions contain 4 inputs for entrance panel common connections, an output to telephones and an input to link multiple PCBs together for systems that require more than 4 entrances. Voltage to each entrance panel (12Vdc) is fused and indicated by an LED.
The VX123V contains an active LED for all entrance inputs to display when a certain entrance is in use. 2206N, The 2206N is a powerful device which allows the system to be expanded up to 998 apartments. There are two applications in which this unit can be used.
The first application is a system with both main entrances and sub entrances/blocks (Main entrances call all apartments on a system and sub/block entrances only call the apartments in their own block). In this application, one 2206N would be required for each block. The second application is a single level system with up to 10 entrances whereby all entrances need to call all apartments.
In this application, a 2206N would be required for every 180 apartments and could be used to expand the system up to 998 apartments(i.e. 500 apartments would require a minimum of 3x2206N). VX123A / VX123V-2206N-.
Key features
- VX123A and VX123V 4-Entrance audio or video switching cards with LED indication
- Connect VX123 boards together for systems with more than 8 entrances
- 2206N Bus exchance device allowing for up to 998 apartments or a system containing main entrances and sub entrances
If you are matching this to an existing installation, work from the 2206A part number rather than the description.
Specifications
Specifications
| Brand Name | Videx |
|---|---|
| Manufacturer Part Number | 2206A |
