Videx 2206V bus exchange device

Please note: this is a non-returnable item (excluding faulty goods)

Videx 2206V is a bus exchange device.

A range of VX2200 system entrance switching devices for both audio and video systems-VX123A / VX123V, 4 door audio and video switching PCBs respectively. Both versions contain 4 inputs for entrance panel common connections, an output to telephones and an input to link multiple PCBs together for systems that require more than 4 entrances. Voltage to each entrance panel (12Vdc) is fused and indicated by an LED.

The VX123V contains an active LED for all entrance inputs to display when a certain entrance is in use.2206N, The 2206N is a powerful device which allows the system to be expanded up to 998 apartments. There are two applications in which this unit can be used. The first application is a system with both main entrances and sub entrances/blocks (Main entrances call all apartments on a system and sub/block entrances only call the apartments in their own block).

In this application, one 2206N would be required for each block. The second application is a single level system with up to 10 entrances whereby all entrances need to call all apartments. In this application, a 2206N would be required for every 180 apartments and could be used to expand the system up to 998 apartments(i.e.

500 apartments would require a minimum of 3x2206N). VX123A / VX123V-2206N-.

Key features

• VX123A and VX123V 4-Entrance audio or video switching cards with LED indication
• Connect VX123 boards together for systems with more than 8 entrances
• 2206N Bus exchance device allowing for up to 998 apartments or a system containing main entrances and sub entrances
