Videx 4534X-2/M camera video module, IP65

Please note: this is a non-returnable item (excluding faulty goods)

Videx 4534X-2/M is a camera video module.

4000 Series speaker / camera module, 4534X, is a combined speech amplifier and camera for the Videx IP system. The module is available with either 0, 1 or 2 buttons (however when connected to 4000 series button expansion modules via the IDC connector can have up to 42 buttons on the system) and have blue backlit name plate windows. It also includes a built-in proximity reader located behind button 1 name plate window.

The total fob / card user capacity for this module is up to 10,000 user fobs / cards (programmable via the IP Wizard). The modules are equipped with a CMOS wide angle color camera with a vertical viewing angle of 80° and a horizontal viewing angle of 170°, complete with 4 bright white illumination LED's. It supports H.264 video codec and supports 1280x720, 640x480, 352x288 (CIF) and 320x240 resolutions and has SIP 2.0 compatibility.

The modules also have 4 DDA compliant call progress LED's to advise the user when the system is busy, a call is in progress, when to speak and when the door is open and includes voice annunciation and acoustic signals. Other programmable settings such as speech volume levels, door relay time, conversation time can be adjusted and setup via the IP Wizard. The modules can be powered directly with 12VDC or via PoE.

All modules contain a speaker and fly lead with microphone which easily fits into a 4000 series frame. Modules attach to the housing frames using a simple but strong clip in system.

Key features

• Compatible with the full range of 4000 series surface and flush back boxes
• Matt 316 marine grade stainless steel (/M) or gun metal grey (/BL) front plate finishes available
• Blue backlit name plate windows
• Wide angle CMOS color camera with white light LED illumination
• DDA Compliant call progress LED's, voice annunciation and acoustic signals
• Contains speaker and fly lead microphone (microphone easily fits within a 4000 series frame)
• Built-in proximity access reader for up to 10,000 user fobs / cards (programmable via PC based IP Wizard)
• H.254 Video codec
• Supported resolutions 1280x720, 640x480, 352x288 (CIF) and 320x240
• SIP 2.0 Compatible
