Videx ESVKX-1S/6286/BL colour videokit, Black

Please note: this is a non-returnable item (excluding faulty goods)

Videx ESVKX-1S/6286/BL is a colour videokit from the 4000 range.

The 4000 series range of "True" 2-wire color videokits with proximity (ESVKX series), are available as flush or surface kits with a choice of 4 different videophone options from the 6200, 6300, 6400 and 6700 series range. Installations couldn’t be easier thanks to the common 2-wire BUS system (VX2300) using two non-polarity twisted pair wires (the system does not require coaxial cable). The videokits are ideal for small-scale "1-to-1" installations or low-rise apartment blocks (up to a total of 12 apartments max. with the inclusion of additional 4000 series button expansion modules), but can also be expanded up to a maximum of 8 entrances where additional 2301N multiple entrance switchers are required.

The ESVKX series videokits are available as 1 or 2-button 4000 series color videokits where the flexible design allows for up to a total of 4 videophones per call button with the facility for intercommunication between the videophones in the same apartment or intercommunication between videophones in different apartments. Other key features of the videokit include; adjustable call tone, conversation time and microphone and speaker volume adjustments, selectable camera recall including external camera input. The combined speaker and camera module (4384X-1 or 4384X-2) entry panel has a built-in color camera with white illumination LED’s that provides the best quality picture in any lighting condition.

It also includes a built-in proximity reader (located behind the panel’s nameplate window) which is capable of storing up to 50 user keyfobs. It also has a lock release relay (C, NO and NC) with selectable capacitor discharge, push to exit input, call progress reassurance tones and DDA compliant call progress LED’s; BUSY, CALL, SPEAK and DOOR OPEN.

Key features

• Available as 1 and 2 button color videokits (however expandable up to 12 buttons)
• Flush or surface mount door entrance panels based on the 4000 series range
• Videokits available with either 6200 series, 6300 series, 6400 series or 6700 series videophones
• Expandable up to 8 entrances (with additional 2301N multiple entrance switchers)
• Call a total of up to 4 videophones per call button
• Intercommunication between videophones in same apartment or between different apartments
• DDA Compliant call progress LED's and reassurance tones
• High-quality color camera with 4 illumination LED's
• Selectable camera recall facility (including external camera input)
• PTE Input and built-in dry contact relay (including selectable capacitor discharge)

If you are matching this to an existing installation, work from the ESVKX-1S/6286/BL part number rather than the description.
