Videx CVKC4K2 door entry kit, Flush Mount
About this product
Please note: this is a non-returnable item (excluding faulty goods)
Videx CVKC4K2 is a door entry kit from the 4000 range.
Surface or flush 1 and 2 button 4000 series non-coax (balanced video pair) colour videokits with codelock. The 4000 series video entry panels include DDA compliant reassurance tones and call progress LED's for call in progress, system busy, speak and door open. The videokits also include a 4901 codelock module which has 3 programmable access codes, 3 relay contact outputs (C, NO and NC) with 2 push to exit inputs (for relays 1 and 2 only).
The relays can be programmed from 1-99 seconds or programmed with 00 for latching output and have adjustable blue back-lit numeric keypad buttons. The flexible design allows for the addition of up to a total of 4 door entry panels (with additional 506N relays) with up to 4 video handsets per call button. The system also benefits from intercommunication calls between the videophones within the same apartment or between videophones in different apartments.
The videokits are available with the choice of a 6200 series videophone with handset or a 6300 series, 6400 series or 6700 series hands free monitor. Features of both videophone and hands free monitors include an adjustable 3 level call tone, brightness and contrast controls, camera recall (selectable), timed privacy facility with LED indication.
Key features
- Surface or flush 1 or 2 button videokit options
- 4000 Series video entry panels available in a matt 316 grade stainless steel finish
- Kits available with either a 6200 series videophone, 6300 series, 6400 series or 6700 series hands free monitor
- Video entry panel with DDA compliant call progress LED's, reassurance tones and acoustic signals
- Expandable up to 4 entrances (with additional 506N relays)
- Call a total of 4 videophones/hands free monitors off each call button
- Intercommunication between videophones in same apartment or between different apartments
- 3 code, 3 relay codelock module with blue back-lit numeric keypad
If you are matching this to an existing installation, work from the CVKC4K2 part number rather than the description.
Specifications
Technical information
Product information
Miscellaneous
Specifications
| Brand Name | Videx |
|---|---|
| Manufacturer Part Number | CVKC4K2 |
| Product Series | 4000 |
Technical information
| Connectivity Technology | Wired |
|---|
Product information
| Mount Type | Flush Mount |
|---|
Miscellaneous
| Indoor or outdoor use | Indoor |
|---|
