Videx CVR4KV-9S/CL door entry kit, Grey
About this product
Please note: this is a non-returnable item (excluding faulty goods)
Videx CVR4KV-9S/CL is a door entry kit from the 4000 range.
3 - 12 way vandal resistant 4000 Series video kits based on the VX2200 non-coax 6 wire video system. Door panels have 3 call progress LEDS - "Call in progress", "Speak" and "Door open". The day/night colour CCD camera is wide angle and illuminated using infra-red LED's.
Included in the kit is a 6000 Series videophone with a 3.5" high definition LCD TFT colour display, camera recall facility, door open button, 2 spare service buttons with LED indication, Privacy, 2 level call tone adjustment and contrast / brightness controls. A maximum 3 videophones may be called from a single button. The codelock has 3 codes, 3 changeover relay outputs and an override input.
It can be programmed from 1-99 seconds or latching output.
Key features
- 3 - 12 Button colour video kits based on the vandal resistant 4000 Series
- Surface or flush mount door panel
- Colour CCD day/night camera with infra-red illumination
- Expandable up to 10 entrances
- Call a total of 3 videophones off each call button
- 3 code, 3 relay coded access keypad
If you are matching this to an existing installation, work from the CVR4KV-9S/CL part number rather than the description.
Specifications
Physical characteristics
Power description
Product information
Miscellaneous
Attributes
Specifications
| Brand Name | Videx |
|---|---|
| Manufacturer Part Number | CVR4KV-9S/CL |
| Product Series | 4000 |
Physical characteristics
| Colour | Grey |
|---|---|
| Material | Stainless Steel |
Power description
| Input Voltage | 12V DC |
|---|
Product information
| Mount Type | Flush Mount, Surface Mount |
|---|
Miscellaneous
| Indoor or outdoor use | Indoor |
|---|
Attributes
| Input Voltage | 12V DC |
|---|
Videx CVR4KV-9S/CL door entry kit, Grey
