Videx 4844/M expansion intercom module, IP65

£ 46 41
(Incl. VAT)

About this product

Please note: this is a non-returnable item (excluding faulty goods)

Videx 4844/M is an expansion intercom module.

4000 Series button expansion modules are used to achieve the required amount of call buttons for audio or audio / video door entry systems. Modules are available with 2, 3, 4 and 5 buttons. Double button modules are also available with 4, 6, 8 and 10 buttons, where 2 buttons share the same name plate window.

There are two variations of button modules available depending on the 4000 series audio or audio / video system being installed. Each module has a terminal connection that houses 2 terminals for each button where the buttons, depending on jumper settings, can have a common terminal or each button can have its own common. 4042 Up to 4045 and 4042D up to 4045D for audio / video 4000 series modules with the built-in IDC connector.

Each module has a series of jumpers that when set in a specific position configures the buttons to work through the IDC connector. These button modules also require CFL17 (supplied) and CFL45 IDC ribbon cables to link between modules.

Key features

  • Compatible with the full range of 4000 series surface and flush back boxes
  • Matt 316 marine grade stainless steel (/M), mirror stainless steel (/S) or gun metal grey (/BL) front plate finishes available
  • Blue backlit name plate windows
  • Robust tactile push buttons
  • 2, 3, 4, 5 Button modules available
  • 2, 3, 4, 5 Button modules with IDC connector
  • 4, 6, 8, 10 Double button modules (2 buttons share the name plate window)

If you are matching this to an existing installation, work from the 4844/M part number rather than the description.

£ 46 41
Ships from United Kingdom
28 days hassle free returns
Secure payment transactions
Price
£46.41 Incl. VAT
Add a WME Product Care Plan Includes warranty, replacement and repairs backed by WME
Why add a product care plan:
  • Full breakdown support
  • Full replacement if we can't repair your product within 10 days
  • All parts, labour and callouts included if necessary
  • Extended manufacturer warranty with faster turn arounds
  • Excludes accidental & cosmetic damages
By selecting one of these plans you agree to purchase WME Care Plan. Please read the Terms and Important information to ensure WME Care Plan is right for you. Compare prices of extended warranties for electrical goods at www.compareextendedwarranties.co.uk
WME Care
Technical Details
Specifications
Brand Name
Videx
Manufacturer Part Number
4844/M
Product Type
Button Modules
Certifications
Ingress protection
IP65
Physical characteristics
Width
103.00mm
Power description
Input Voltage
12V AC, DC
Miscellaneous
Compatibility
3+1 audiokits, 4+1 audio and video systems, 4000 series GSM audiokits, 4000 series intercommunicating systems, 4000 series surface and flush rainshields, 5+1 audio and video systems with privacy of speech, All 4000 series surface and flush back boxes, VX2200 audio and video speaker modules, VX2200 digital audio and video, VX2300 audio and video speaker modules, VX2300 digital audio and video
Attributes
Compatibility
3+1 audiokits, 4+1 audio and video systems, 4000 series GSM audiokits, 4000 series intercommunicating systems, 4000 series surface and flush rainshields, 5+1 audio and video systems with privacy of speech, All 4000 series surface and flush back boxes, VX2200 audio and video speaker modules, VX2200 digital audio and video, VX2300 audio and video speaker modules, VX2300 digital audio and video
Input Voltage
12V AC, DC
Specifications
Certifications
Physical characteristics
Power description
Miscellaneous
Attributes

Specifications

Brand Name Videx
Manufacturer Part Number 4844/M
Product Type Button Modules

Certifications

Ingress protection IP65

Physical characteristics

Width 103.00mm

Power description

Input Voltage 12V AC, DC

Miscellaneous

Compatibility 3+1 audiokits, 4+1 audio and video systems, 4000 series GSM audiokits, 4000 series intercommunicating systems, 4000 series surface and flush rainshields, 5+1 audio and video systems with privacy of speech, All 4000 series surface and flush back boxes, VX2200 audio and video speaker modules, VX2200 digital audio and video, VX2300 audio and video speaker modules, VX2300 digital audio and video

Attributes

Compatibility 3+1 audiokits, 4+1 audio and video systems, 4000 series GSM audiokits, 4000 series intercommunicating systems, 4000 series surface and flush rainshields, 5+1 audio and video systems with privacy of speech, All 4000 series surface and flush back boxes, VX2200 audio and video speaker modules, VX2200 digital audio and video, VX2300 audio and video speaker modules, VX2300 digital audio and video
Input Voltage 12V AC, DC

Videx 4844/M expansion intercom module

Videx 4844/M expansion intercom module, IP65

Who this is for

For the installer — this is the expansion intercom module supplied under Videx part number 4844/M. Specify it by that part number.

The entries in the specification table are the ones held against this part number. Anything not listed there is not stated by us, and should be confirmed against the manufacturer's own documentation.

In plain English: this is an expansion intercom module made by Videx. The part number 4844/M is the manufacturer's own code for this exact version of it.

Similar-looking items in the same family often differ only by a suffix on that code. If you are replacing something, match the code rather than the picture.

Buying this in the UK

We are a UK supplier and this expansion intercom module is sold and shipped from the UK. Prices are shown in pounds sterling.

This item is non-returnable, excluding faulty goods. That restriction comes from the manufacturer's own terms for this line.

We do not quote a warranty term for this part. Every supplier-stated term we have checked against the manufacturer's own document has turned out to be wrong, so we would rather say nothing than say something we cannot stand behind.

Ask us and we will check it for you. Your statutory rights are unaffected.

Stock on this line moves, and lead times move with it. Ask us for the current position before you commit to a date on site.

Questions we get asked

Is this the exact expansion intercom module I have been quoted? Check the manufacturer part number 4844/M against your quote. That code is the only reliable identity for this item.

Is there a datasheet? Not on this listing.

Can you check compatibility for us? Ask before you order and we will check it against the manufacturer's own documentation. We do not state compatibility that the record does not carry.

Why does the listing not answer every question? Because the specification held against 4844/M answers some questions and not others. We would rather leave a gap visible than fill it with something we cannot show you.

What if I order the wrong version? Tell us the installation you are matching and we will work back to the part number with you. That is a faster conversation than a return.

Do you hold this in stock? Availability on this line changes through the week, so the honest answer is to ask us on the day. We will give you the current position rather than a general one.

Videx 4844/M expansion intercom module
Videx

Videx 4844/M expansion intercom module, IP65

£46.41

Please note: this is a non-returnable item (excluding faulty goods)

Videx 4844/M is an expansion intercom module.

4000 Series button expansion modules are used to achieve the required amount of call buttons for audio or audio / video door entry systems. Modules are available with 2, 3, 4 and 5 buttons. Double button modules are also available with 4, 6, 8 and 10 buttons, where 2 buttons share the same name plate window.

There are two variations of button modules available depending on the 4000 series audio or audio / video system being installed. Each module has a terminal connection that houses 2 terminals for each button where the buttons, depending on jumper settings, can have a common terminal or each button can have its own common. 4042 Up to 4045 and 4042D up to 4045D for audio / video 4000 series modules with the built-in IDC connector.

Each module has a series of jumpers that when set in a specific position configures the buttons to work through the IDC connector. These button modules also require CFL17 (supplied) and CFL45 IDC ribbon cables to link between modules.

Key features

If you are matching this to an existing installation, work from the 4844/M part number rather than the description.
