Videx VRBB130X400 flush back box, Surface Mount
About this product
Please note: this is a non-returnable item (excluding faulty goods)
Videx VRBB130X400 is a flush back box from the VR130 range.
Vandal resistant VR130 series flush boxes with an 18mm bezel surround and manufactured from 316 marine grade brushed stainless steel with galvanised stainless steel flush box. Each bezel box has 3x20mm knockouts evenly spaced along the centre (base) of the flush box. Each bezel box is fitted with either four or six M5 cage nuts (depending box size) and also fitted with an M4x10mm earth stud to allow the VR130 panels earth strap to be connected.
Four or six 4mm fixing holes (depending box size) are located on the base of the flush box to allow for easy flush mounting.
Key features
- Surface mount 130x400mm galvanised steel backbox
- Includes rainshield for added protection
- 30mm Brushed 12 gauge stainless steel design
- Fits standard VR130 sizes for compatibility
- Compatible with Videx IP and VR130 Series panels
- Contains M5 lock nuts for secure installation
- 20mm Knockout for efficient cable routing
If you are matching this to an existing installation, work from the VRBB130X400 part number rather than the description.
Specifications
General information
Physical characteristics
Product information
Miscellaneous
Specifications
| Brand Name | Videx |
|---|---|
| Manufacturer Part Number | VRBB130X400 |
| Product Series | VR130 |
General information
| Packaged Quantity | 1 |
|---|
Physical characteristics
| Height | 400.00mm |
|---|---|
| Material | Galvanised Steel |
| Width | 130.00mm |
Product information
| Mount Type | Surface Mount |
|---|
Miscellaneous
| Indoor or outdoor use | Indoor |
|---|
Videx VRBB130X400 flush back box, Surface Mount
