Videx ESVRK-2/6286 flush mount
About this product
Please note: this is a non-returnable item (excluding faulty goods)
Videx ESVRK-2/6286 is a flush mount.
Videx's Vandal Resistant range of "true" two wire bus colour videokits are available as 1 button or 2 button flush or surface kits (ESVRK series). The videokits are available with a selection of different videophone options including the 6200 series (3.5" videophone), 6300 series (3.5" handsfree), 6400 series (4.3" hands-free) or 6700 series (7" hands-free) 2 wire bus videophone. Installations couldn't be easier thanks to the common 2 wire bus using two non-polarity wires.
The videokits are ideal for small scale "one to one" installations or low-rise apartment blocks (up to 12 apartments max.), but can also be expanded up to 8 entrances (max.) where additional 2301N multiple entrance switchers are required. Key features of the kits include - an integrated high quality colour camera with 4 illumination LED's and auto iris lens (wide angle camera optional) and includes an external camera input. DDA compliant call progress LED's (busy, call, speak and door open) with reassurance tones, privacy feature, built-in lock relay with capacitor discharge output option, camera recall function, microphone, speaker and balance adjustments and an intercommunication facility between videophones in different apartments or between videophone extensions within the same apartment.
Key features
- Vandal Resistant entrance panels are manufactured from 12 gauge 316 grade stainless steel
- Vandal Resistant entrance panels can be expanded from 1 up to 12 call buttons for larger systems
- Available with either the 6286 (standard), 6388, 6488 or 6788 series videophones each including melody selection, timed privacy features and intercommunication facility
- High quality colour camera with 4 illumination LED's and 10° camera tilt adjustment
- Option for wide angle camera (170° viewing angle)
- DDA compliant call progress LED's and reassurance tones
- Selective camera recall facility and external camera input
- PTE input and lock release relay or capacitor discharge output
- Adjustable microphone, speaker and balance controls
- Expandable up to 8 entrances (two 2301N entrance switchers required)
If you are matching this to an existing installation, work from the ESVRK-2/6286 part number rather than the description.
Specifications
Physical characteristics
Specifications
| Brand Name | Videx |
|---|---|
| Manufacturer Part Number | ESVRK-2/6286 |
Physical characteristics
| Durability | Vandal Resistant |
|---|
