Videx 4K-9S GSM kit, Grey

Please note: this is a non-returnable item (excluding faulty goods)

Videx 4K-9S is a GSM kit.

Introducing the new 4G GSM audiokits that are manufactured in the familiar modular 4000 series range with a 316 grade stainless steel matt finish. They are available from single call button applications up to 12 button kits (surface or flush), however is expandable up to 50 call buttons, all with the facility to divert to additional numbers if the first is busy or unanswered (up to 3 divert numbers per button). The 4G GSM intercom module is able to connect to 2G, 3G and 4G networks and is designed for global use.

The 4G GSM audiokits have all the original features of the previous GSM PRO series kits, however they now include new programming features. In addition to the existing 1000 dial to open numbers (with access levels) it can store up to 32 temporary dial to open numbers that are programmable from 1 to 255 hr. It also includes an automatic time correction feature (for when the 4G GSM is used in different time zones) and daylight saving time adjustments.

The RS485 bus connectivity allows the 4G GSM module to be expanded to a networkable access control system (up to a total of 8 devices) which can include both proximity, using the new Art. 4850R off board expansion reader, and coded access, using the new Art. 4903 keypad.

Programming can also be carried out using the GSMSK PC software either connected via the micro USB port or RS485 bus or remotely via the new over the air feature (programming is still carried out using the PC software however the 4G GSM module is not physically connected to a PC directly by the micro USB port or RS485 bus). An event log (up to 4000 stored events) is maintained within the 4G GSM module and can be downloaded via the USB port or RS485 bus connection using the PC software or can be viewed remotely and monitored in real time using the online web browser events application (the events can be viewed on any device such as a smartphone, tablet or PC).

Key features

• Compatible with 2G, 3G and 4G networks
• 1-Button up to 12 button kits available (surface or flush)
• Expandable up to 50 call buttons using a combination of additional 4000 series button modules and surface or flush back boxes
• DDA Compliant voice annunciation and call progress LED's
• 4-Telephone numbers per call button (1 primary and 3 diverts)
• 1000 Dial to open numbers (which can each be assigned with an access level)
• 32 Temporary dial to open numbers (programmable from 1 to 255 hours)
• 1000 User integrated proximity access
• 1-Programmable call button timeband
• Up to 10 programmable access control timebands

If you are matching this to an existing installation, work from the 4K-9S part number rather than the description.
